UNV - EXC2614S-X33-W-VD2 - 4MP Starlight 33X IR Intelligent Explosion-proof Bullet IP Camera
Product Overview
The Uniview EXC2614S-X33-W-VD2 is a 4MP LightHunter infrared intelligent explosion-proof network bullet camera designed for demanding industrial surveillance environments. It combines a 33x optical zoom lens, 200 m infrared illumination, advanced perimeter analytics, and a sealed 316L stainless-steel housing with ATEX and IECEx certification.
The camera supports AC 220 V or IEEE 802.3at PoE power, H.265/H.264/MJPEG encoding, edge storage, and IP68 protection for reliable operation in hazardous and outdoor locations.
Key Configuration
Model: EXC2614S-X33-W-VD2 | Resolution: 4MP (2688 × 1520) | Lens: 6.5–214.5 mm motorized lens with 33x optical zoom | Connectivity: 10/100 Mbps RJ45, ONVIF Profile S/G/T/M | Protection: IP68, NEMA 4X, ATEX and IECEx certified
Key Features
- · 4MP 1/1.8-inch CMOS sensor with LightHunter low-light performance down to 0.002 lux in color
- · 6.5–214.5 mm motorized lens with 33x optical zoom
- · 200 m infrared illumination distance with automatic or manual control
- · 120 dB optical wide dynamic range, 2D/3D DNR, HLC, BLC, digital defog, and EIS
- · Smart Intrusion Prevention with cross-line, intrusion, enter-area, and leave-area detection
- · Target classification and false-alarm filtering for people, vehicles, and non-motor vehicles
- · Five-stream video capability with H.265, H.264, and MJPEG compression
- · MicroSD edge storage up to 512 GB, with ANR and NAS support
- · Two-way audio, alarm input/output, RS485, and ONVIF Profile S/G/T/M integration
- · 316L stainless-steel explosion-proof housing with IP68 and NEMA 4X protection
Technical Context
The camera combines long-range motorized zoom with infrared illumination and high-sensitivity imaging to maintain identification detail across wide distances and low-light scenes. Smart Intrusion Prevention analyzes classified targets, helping distinguish people and vehicles from irrelevant motion before generating perimeter events.
Installation Notes
Designed for hazardous and outdoor installations from -40°C to 60°C with humidity up to 95% RH, non-condensing. Power is supplied through AC 220 V (100–240 V) or IEEE 802.3at PoE. Optional explosion-proof mounting accessories include wall brackets, control boxes, and flexible conduit.
| Product Information | |
| Product Model | EXC2614S-X33-W-VD2 |
| Product Type | 4MP LightHunter infrared intelligent explosion-proof network bullet camera |
| Housing Material | 316L stainless steel |
| Explosion-Proof Marking | ATEX: Ex II 2GD Ex db IIC T6 Gb / Ex tb IIIC T80°C Db IECEx: Ex db IIC T6 Gb / Ex tb IIIC T80°C Db |
| Standards | NEMA 4X |
| Compliance | NDAA Compliant |
| Camera and Lens | |
| Maximum Resolution | 4 Megapixels |
| Image Sensor | 1/1.8" CMOS |
| Minimum Illumination | Color: 0.002 lux at F1.5, AGC on Black and white: 0.001 lux at F1.5, AGC on 0 lux with IR illumination |
| Day/Night | IR-cut filter with automatic switching |
| Shutter | Auto / Manual, 1–1/100,000 s |
| Signal-to-Noise Ratio | >56 dB |
| Wide Dynamic Range | 120 dB |
| Focal Length | 6.5–214.5 mm |
| Optical Zoom | 33× |
| Iris | F1.5–F5.19 |
| Field of View | Horizontal: 56.7°–2.60° Vertical: 33.8°–1.46° Diagonal: 66.9°–3.20° |
| DORI Distance | |
| Detect | 110.2–2668.2 m (361.5–8753.9 ft) |
| Observe | 44.1–1067.3 m (144.6–3501.6 ft) |
| Recognize | 22.0–533.6 m (72.3–1750.8 ft) |
| Identify | 11.0–266.8 m (36.1–875.4 ft) |
| Infrared Illumination | |
| IR Illumination Distance | Up to 200 m (656.2 ft) |
| Light Control | Auto / Manual |
| Video | |
| Main Stream | 4MP (2688 × 1520) at up to 30 fps |
| Sub Stream | 2MP (1920 × 1080) at up to 30 fps |
| Third Stream | D1 (720 × 576) at up to 30 fps |
| Fourth Stream | D1 (720 × 576) at up to 30 fps |
| Fifth Stream | D1 (720 × 576) at up to 30 fps |
| Video Compression | H.265, H.264, MJPEG |
| Video Bit Rate | 128 Kbps–16 Mbps |
| Video Streams | Triple-stream support |
| OSD | Up to 10 OSD areas |
| Privacy Masking | Up to 24 areas, with up to 8 areas per scene |
| ROI | Supported |
| U-Code | Supported |
| Image Features | |
| White Balance | Auto, outdoor, fine tune, sodium lamp, locked, Auto2 |
| Noise Reduction | 2D/3D DNR |
| Image Flip | Normal, vertical, horizontal, 180°, 90° clockwise, and 90° anti-clockwise |
| Image Stabilization | EIS using gyroscope |
| HLC | Supported |
| BLC | Supported |
| Defog | Digital defog |
| Intelligent Analytics | |
| Smart Intrusion Prevention | Cross-line detection, intrusion detection, enter-area detection, and leave-area detection |
| Target Classification | Human, vehicle, and non-motor vehicle classification with false-alarm filtering |
| Deep Smart Functions | Deep perimeter protection, anomaly detection, and people counting |
| People Counting | People-flow statistics and personnel-density detection |
| Audio and Events | |
| Audio Compression | G.711U, G.711A |
| Audio Bit Rate | 128 Kbps |
| Two-Way Audio | Supported |
| Audio Suppression | Supported |
| Sampling Rate | 8 kHz, 16 kHz |
| Basic Detection | Motion detection, tampering alarm, audio detection, and custom event detection |
| General Functions | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication, alarm input, and alarm output |
| Storage and Network | |
| Edge Storage | MicroSD card up to 512 GB The memory card can be installed during manufacturing when ordered with the product. |
| Network Storage | ANR and NAS (NFS) |
| Network Protocols | IGMP, RTP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS, SSH |
| Interoperability | SDK and ONVIF Profiles S/G/T/M |
| Client Software | EZStation, UNV-Link, UNV-Link Pro |
| Web Browser | Internet Explorer 10+, Chrome 45+, Firefox 52+, Edge 79+ |
| User Management | Up to 32 users with 3 levels: Administrator, Common User, and Operator |
| PTZ and Interfaces | |
| Home Position | Supported |
| Patrols | 16 |
| Presets | 1024 |
| Serial Interface | 1 × RS-485 |
| Audio I/O | 1 input: 1 kΩ impedance, 2.5 V p-p amplitude 1 output: 600 Ω impedance, 2 V amplitude |
| Alarm I/O | 7 alarm inputs / 2 alarm outputs |
| Network Interface | 1 × RJ-45 10/100 Mbps Base-TX Ethernet |
| Reset Button | Supported |
| RTC | Supported |
| Electrical Specifications | |
| Power Supply | AC 220 V (100–240 V) or PoE IEEE 802.3at |
| Power Consumption | 25.3 W |
| Power Interface | Wires with cold-pressed terminal |
| Surge Protection | 6 kV |
| Mechanical and Environmental | |
| Ingress Protection | IP68 |
| Operating Temperature | -40°C to 60°C (-40°F to 140°F) |
| Operating Humidity | ≤95% RH, non-condensing |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
| Storage Humidity | ≤95% RH, non-condensing |
| Dimensions | 395.4 × 265.9 × 150 mm 15.57 × 10.47 × 5.91 in |
| Weight | 9.79 kg (21.58 lb) |
| Certifications | |
| EMC | CE EMC, FCC |
| Safety | CE LVD, CB, UL/CUL |
| Explosion-Proof Certifications | ATEX and IECEx |
| Environmental Compliance | CE RoHS, WEEE |
| Applicable Standards | EN 55032, EN IEC 61000-3-2, EN 61000-3-3, EN 50130-4, EN IEC 62368-1, EN IEC 60079-0, EN 60079-1, IEC 60079-31, FCC 47 CFR Part 15 |
| Optional Accessories | |
| TR-WM06-L-H | Wall mounting bracket for explosion-proof bullet camera, 316L stainless steel |
| TR-JB13-L | Explosion-proof control box |
| TR-JB16-L | Explosion-proof control box |
| TR-FP10-L | Explosion-proof flexible tube, 316L stainless steel, M25–M25, 1 m |
