UNV - IPC-D312-ADZK - 2MP WDR VF IR Dome Network Camera

Product Overview

The Uniarch IPC-D312-ADZK is a 2MP WDR varifocal infrared dome network camera with a 2.8–12 mm lens. It provides 1080p video, 120 dB true WDR, Smart IR illumination up to 30 m, and human/vehicle detection for dependable surveillance in changing lighting conditions.

The camera supports Ultra 265 compression, edge storage, built-in audio, DC 12 V or PoE power, and IP67/IK10 protection for demanding indoor and outdoor installations.

Key Configuration

Model: IPC-D312-ADZK | Resolution: 2MP, 1920 × 1080 at up to 30 fps | Lens: 2.8–12 mm varifocal, F1.6 | Connectivity: 10/100 Mbps RJ45, ONVIF Profile S/G/T | Protection: IP67, IK10

Key Features

• · 2MP 1/2.7-inch CMOS sensor with 1080p video at up to 30 fps
• · 2.8–12 mm varifocal lens with 111.0° to 36.6° horizontal field of view
• · Smart IR illumination up to 30 m with automatic or manual control
• · 120 dB true WDR for high-contrast lighting conditions
• · Ultra 265, H.265, H.264, and MJPEG video compression
• · 2D/3D digital noise reduction, HLC, BLC, and digital defog
• · Cross-line and intrusion detection based on human-body detection
• · Ultra Motion Detection for human and vehicle targets
• · MicroSD edge storage up to 512 GB with ANR and NAS support
• · IP67 and IK10 protection, 4 kV surge protection, and DC 12 V or IEEE 802.3af PoE power

Technical Context

The varifocal lens allows the viewing angle to be adjusted for wide-area monitoring or more focused scene coverage. True WDR balances bright and dark regions, while Smart IR provides controlled infrared illumination for clear night images across distances up to 30 m.

Installation Notes

The dome housing supports pan adjustment from 3° to 360°, tilt from 0° to 70°, and rotation from 3° to 360°. It operates from -30°C to 60°C with humidity up to 95% RH, non-condensing. Optional junction-box, wall, pole, pendant, corner, and sunshade accessories are available.
