Uniview - IPC2128LR3-DPF28LM-F - UNV 8MP Wide Dynamic Mini Bullet Network Camera
Part number:
IPC2128LR3-DPF28LM-F
Price:
UNV 8MP Wide Dynamic Mini Bullet Network Camera
Optics
- Day/night functionality
- Smart IR , up to 30 m (98 ft) IR distance
- Optical glass window with higher light transmittance
- IR anti-reflection window to increase the infrared transmittance
- 2D/3D DNR (Digital Noise Reduction)
Compression
- Ultra 265, H.265, H.264, MJPEG
- ROI (Region of Interest)
Network
- ONVIF Conformance
Structure
- Wide temperature range: -30°C to 60°C (-22°F to 140°F)
- Wide voltage range of ±25%
- IP67
- 3-Axis
| IPC2128LR3-DPF28LM-F | ||||||
| Camera | ||||||
| Sensor | 1/3", 8.0 megapixel, progressive scan, CMOS | |||||
| Lens | 2.8mm@F2.0 | |||||
| DORI Distance | Lens | Detect(m) | Observe(m) | Recognize(m) | ||
| 2.8mm | 84 | 33.6 | 16.8 | |||
| 4.0mm | 120 | 48 | 24 | |||
| Angle of View (H) | 112.7° | |||||
| Angle of View (V) | 60.1° | |||||
| Angle of View (D) | 146.5° | |||||
| Adjustment angle | Pan: 0°~360° | Tilt: 0°~90° | Rotate: 0°~360° | |||
| Shutter | Auto/Manual, 1~1/100000 s | |||||
| Minimum Illumination | Colour: 0.05 Lux (F2.0, AGC ON) 0 Lux with IR on | |||||
| Digital noise reduction | 2D/3D DNR | |||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||
| S/N | >56dB | |||||
| IR Range | Up to 30m (98 ft) IR range | |||||
| Wavelength | 850nm | |||||
| IR On/Off Control | Auto/Manual | |||||
| Defog | Digital Defog | |||||
| WDR | 120dB | |||||
| Video | ||||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | |||||
| H.264 code profile | Baseline Profile, Main Profile | |||||
| Frame Rate | Main Stream:8MP (3840*2160): Max. 20 fps;5MP(2944*1656): Max. 30 fps; 4MP(2560*1440): Max. 30 fps; 2MP(1920*1080): Max. 30 fps Sub Stream:720P (1280*720): Max. 20 fps Third Stream:4CIF (704*576): Max. 20 fps | |||||
| Video Bit Rate | 128 Kbps~16 Mbps | |||||
| OSD | Up to 4 OSDs | |||||
| Privacy Mask | Up to 4 areas | |||||
| ROI | Up to 2 areas | |||||
| Motion Detection | Up to 4 areas | |||||
| Image | ||||||
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |||||
| Digital noise reduction | 2D/3D DNR | |||||
| Smart IR | Support | |||||
| Flip | Normal/Vertical/Horizontal/180° | |||||
| Dewarping | NA | |||||
| HLC | Supported | |||||
| BLC | Supported | |||||
| Network | ||||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL,QoS | |||||
| Compatible Integration | ONVIF(Profile S, Profile T), API | |||||
| Client | EZStation EZView EZLive | |||||
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | |||||
| Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ | ||||||
| Interface | ||||||
| Network | 10/100M Base-TX Ethernet | |||||
| Certifications | ||||||
| Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 | |||||
| General | ||||||
| Power | 12 V DC±25%, PoE (IEEE802.3 af) | |||||
| Power consumption: Max 5.5W | ||||||
| Dimensions (L × W × H) | 167.3×62.9×62.7mm (6.6" ×2.5" ×2.5") | |||||
| Net Weight | 0.45kg (0.99lb) | |||||
| Material | Metal | |||||
| Working Environment | -30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing) | |||||
| Strorage Environment | -30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing) | |||||
| Surge Protection | 2KV | |||||
| Ingress Protection | IP67 | |||||
| Reset Button | Supported | |||||
