Uniview - IPC3618LB-AF28K-DL - 8MP WDR Dual Light Eyeball Network Camera
• High quality image with 8 MP, 1/2.7" CMOS sensor
• 8 MP (3840 × 2160)@20 fps; 5 MP (3072 × 1728)@30/25 fps; 4 MP (2560 × 1440)@30/25 fps; 1080P (1920 × 1080)@30/25 fps
• Ultra 265, H.265, H.264, MJPEG
• 120 dB true WDR technology enables clear image in strong light scene
• Supports 9:16 corridor mode
• Built-in mic
• Smart IR, up to 30 m (98.4 ft) IR distance
• MicroSD, up to 512 GB
• IP67 protection
• Supports PoE power supply
• 3-axis
| Camera | |
| Max Resolution / Sensor | 8 MP / 1/2.7" CMOS |
| Min. Illumination (Color/Light) | 0.005 Lux (F1.6, AGC ON), 0 Lux with light |
| Day/Night / Shutter | IR-cut filter with auto switch (ICR) / Auto/Manual, 1 ~ 1/100000s |
| Adjustment Angle (Tilt) | Pan: 0° to 360°, Tilt: 0° to 80°, Rotate: 0° to 360° |
| S/N / WDR | > 56 dB / 120 dB |
| Lens | |
| Focal Length / Lens Type | 2.8 mm / Fixed |
| Iris Type / Iris | Fixed / F1.6 |
| Field of View (H/V/D) | H: 100.8°, V: 55.8°, D: 105.7° |
| DORI Distance | |
| DORI Distance (Detect) | 84.0 m (275.6 ft) |
| DORI Distance (Observe) | 33.6 m (110.2 ft) |
| DORI Distance (Recognize) | 16.8 m (55.1 ft) |
| DORI Distance (Identify) | 8.4 m (27.6 ft) |
| Illuminator | |
| Supplemental Light | Dual light (IR and Warm Light) |
| Illumination Distance (IR/Warm) | 30 m (98.4 ft) |
| Control / Wavelength | IR On/Off and Light On/Off Auto/Manual / 850 nm |
| Video | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG (Baseline/Main/High profile) |
| Frame Rate (Main Stream) | 8 MP (3840 × 2160), max. 20 fps (Up to 5 MP at 30 fps) |
| Video Bit Rate / Stream | 128 Kbps to 16 Mbps / Dual streams |
| OSD / Privacy Mask / ROI / U-code | Up to 4 OSDs / Up to 4 areas / Support / Support |
| Image | |
| Digital Noise Reduction / Smart IR | 2D/3D DNR / Support |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2, Area white balance |
| Features | HLC (Support), BLC (Support), Defog (Digital defog) |
| Audio | |
| Compression / Bitrate | G.711U, G.711A / 64 Kbps (Sampling Rate 8 kHz) |
| Two-way Audio / Suppression | N/A / Support |
| Built-in Mic / Speaker | Support / N/A |
| Intelligent Features | |
| Basic Detection | Motion detection, Ultra motion detection (human/vehicle), Tampering alarm, Audio detection |
| Storage & Network | |
| Edge Storage / Network Storage | MicroSD, up to 512 GB / ANR, NAS (NFS) |
| Compatible Integration | ONVIF (Profile S, G, T), API, SDK |
| General & Environment | |
| Power / Power Consumption | DC 12 V±25%, PoE (IEEE 802.3af) / Max. 5.3 W |
| Dimensions (Ø × H) / Weight | Ø117.8 mm × 99.7 mm (Ø4.6" × 3.9") / 0.31 kg (0.68 lb) |
| Protection Rating | IP67 |
| Working Environment | -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉) |
| Surge Protection | 4 KV |
| Certification | |
| EMC / Safety / Environment | CE-EMC, FCC / CE LVD, UL/CUL / CE-RoHS, WEEE, Packaging |
| Web Client Language | 13 Languages |
The IPC3618LB-ADF28K-DL camera is equipped with an 8 MP 1/2.7" CMOS sensor, providing a maximum resolution of 3840 × 2160 in the main stream at up to 20 frames per second. The optics feature a fixed lens with a focal length of 2.8 mm and an F1.6 aperture, resulting in a wide horizontal field of view of 100.8°. Illumination is handled by a Dual Light system, which incorporates both Smart IR and Warm Light, each capable of providing supplemental lighting up to a distance of 30 meters (98.4 ft). Video compression is supported via Ultra 265, H.265, H.264, and MJPEG, and the camera supports dual streaming.
Image processing features include 120 dB Wide Dynamic Range for optimizing visibility in scenes featuring intense light contrast. 2D/3D Digital Noise Reduction is applied to clean up video signals, especially in dark conditions, and Smart IR automatically adjusts infrared intensity. The camera supports other functions like Backlight Compensation, Highlight Compensation, and Digital Defog. It is equipped with a built-in microphone for localized audio monitoring. The camera has an IP67 ingress protection rating against dust and water. It is designed for operation in temperatures ranging from -30 °C to 60 °C (-22 °F to 140 °F). Power is supplied via either DC 12 V or Power over Ethernet, with a maximum power consumption of 5.3 W.
