The R-ECA is part of Luminys’s access control product range. Luminys access control solutions are built for flexibility and scalability and provide reliable, secure access for applications of all sizes.
Key Technologies
USB integration allows for seamless credential enrollment, streamlining management with plug-and-play USB connectivity.
Features:
- Read and Issue MIFARE (IC) Cards
- USB 2.0 Port
- Plug-and-Play
- Indicator Light
- USB Plug-and-Play Connection
- Enrolls Credentials Directly to Access Cards
- Compact Design for Desktop Use
- Supports MIFARE (IC) Cards
Certifications and Compliance
- NDAA Compliant
- FCC
| Specification | Details |
| System | |
| Card Reading Frequency | 13.56 MHz |
| Card Issuing Distance | 1.2 in. to 2.0 in. (3.0 cm to 5.0 cm) |
| Supported Card Type | IC Card (MIFARE card) |
| Status Indicator Light | • Solid Red: Abnormal Operation orFailed to Issue Card• Solid Green: Operation Normal orCard Issued Successfully |
| Buzzer | Built-In |
| Electrical | |
| Power Supply | 5 VDC, 0.5 A |
| Power Consumption | • Standby: ≤ 1.0 W• Working: ≤ 1.7 W |
| Construction | |
| Gross Weight | 0.2 kg (0.4 lb) |
| Product Dimensions | 4.1 in. x 3.0 in. x 0.8 in.(105.0 mm x 75.0 mm x 20.0 mm) |
| Package Dimensions | 7.6 in. x 5.2 in. x 2.1 in.(192.0 mm x 132.0 mm x 54.0 mm) |
| Operating Temperature | –22 °F to 140 °F (–30 °C to 60 °C) 5% to 95% (RH), Non-Condensing |
| Material | PC and ABS |
| Certifications and Compliance | |
| Certifications | FCC |
