AW-IHH-0100 - EOL

Industrial 1xGE 95W PoH/PoE Injector.

Features:

IP Camera Compatibility

• Video Resolution Megapixel/D1/VGA
• Video Compression MJPEG/MPEG-4/H.264/H.265
• Compatible Camera List VIVOTEK IEEE 802.3at / 60W UPoE / 95W PoH/ PoE Network Cameras

Ethernet

• Gigabit Ethernet (RJ45) 1

Standards

• IEEE 802.3 10-BASE-T (Ethernet) Supported
• IEEE 802.3u 100-BASE-TX (Fast Ethernet) Supported
• IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet) Supported
• IEEE 802.3af Power over Ethernet Supported
• IEEE 802.3at Power over Ethernet Plus Supported

Transmission Media

• 10Base T Cat. 3, 4, 5 UTP/STP
• 100Base TX Cat. 5, 5e UTP/STP
• 1000Base T Cat. 5e, 6, 7 UTP/STP

PoE Function

• Number of PoE Out Ports 1
• Max. PoE Output Power/Per Port 56VDC/95W
• 802.3at/af Standard Compatible Yes
• Over Current Protection Supported
• Circuit Shorting Protection Supported
• Total PoE Power Budget 95W
• Power Pin Assignment 1/2(-), 3/6(+), 4/5(+), 7/8(-)
• PoE PD Auto Detection Yes

General

• LED Indicators Power, Mode A/B, 4Pair, PoE
• Power Input PW1: 50V-56VDC Input, PW2: 50V-56VDC Input, Redundant Power Backup
• Power Consumption 97W
• Housing Rugged Metal, IP30 Protection
• Installation DIN-rail Mounting and Wall Mounting
• MTBF 510,304 hours
• Dimensions 103.5 (L) x 32 (W) x 81.5 (H) mm
• Weight 0.14 kg
• Operating Temperature -40°C ~ 75°C (-40°F ~ 167°F)
• Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F)
• Humidity Operating: 5~95% (Non-condensing), Storage: 5~95% (Non-condensing)
• Safety Certifications CE, C-Tick, FCC, VCCI, LVD

Accessories

• Included Accessories QIG, Terminal Block, DIN-rail Brackets, Wall Mount Kit
• Optional Power Supply
• Din Rail Power Supply:
• NDR-120-48: 90~264VAC In, 48~54VDC/120W Out, -20°C ~ 70°C
• Wall Mount Power Supply:
• HLG-120H-54: 90~305VAC In, 54VDC/120W Out, -40°C ~ 70°C
