- 640x512 thermal resolution
- NETD < 40 mK @ F1.0
- Video Analytics (Intrusion, Line Crossing)
- Object Classification, Trigger by human/vehicle
- Temperature Measurement & Alarms
| System Information | - |
| CPU | Multimedia SoC (System-on-Chip) |
| Flash | 16GB |
| RAM | 1GB |
| Camera Speci cations | - |
| Image Sensor | Uncooled VOx Micro bolometer |
| Max. Resolution | Effective pixels: 640x512 Image scale up to: 1280x1024 |
| Lens Type | Fixed-focal (Thermal lens) |
| Focal Length | f = 15 mm |
| Aperture | F1.0 |
| Iris Type | Fixed iris |
| Field of View | 32° (Horizontal) 26° (Vertical) |
| Pan/Tilt/Zoom Functionalities | ePTZ: 4x digital zoom |
| Storage | MicroSD/SDHC/SDXC card (256GB capacity supported) |
| Pixel Size | 12 µm |
| Spectral Range | 8 ~ 14 µm |
| Sensitivity | NETD < 40 mK |
| Video | - |
| Compression | H.265, H.264 |
| Maximum Frame Rate | 25 fps @ 1280x1024 |
| Maximum Streams | 2 simultaneous streams |
| Main Stream | 25fps @ 1280x1024, 1280x720, 640x512 |
| 2nd Stream | 25fps @ 704x576 , 352x240, |
| Video Streaming | Adjustable resolution, CBR/VBR, Smart Encode |
| Image Settings | General settings video title and time stamp overlay, video orientation ( ip, mirror, rotation) Thermal settings white balance, image adjustment (brightness, contrast, sharpness) Privacy mask Scheduled pro le settings |
| Audio | - |
| Audio Capability | Two-way audio |
| Compression | G.711, RAW_PCM |
| Interface | External microphone input, External line output |
| Network | - |
| Users | Live viewing for up to 10 clients |
| Security | Access list, Password protection, user access log, user account management |
| Protocols | IPv4/IPv6, HTTP, RTSP/RTP/RTCP, TCP/UDP, DHCP, DNS, PPPOE, SMTP, HTTPS, 802.1x, QOS, NTP, TCP/IP, FTP, UPnP, DDNS, ICMP, IGMP |
| Interface | 10 Base-T/100 Base-TX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
| ONVIF | Pro le G, S, T supported, speci cation available at www.onvif.org |
| AI Analytics | - |
| Compute Capability | SoC with built-in hardware deep learning accelerator (4T) |
| Application | Temperature measurement alarms (difference, threshold, section, rise), Early Fire Detection (Fire spot detection, Smoking detection) VCA (Intrusion, Single line crossing, Double line crossing, Loitering, Wrong way, Enter, Leave) Support VCA alarms triggering by person, car, person or car; Support temperature alarms triggering by ignoring person, car, person or car |
| Solution Integration | - |
| Video motion detection | Smart motion detection |
| Alarm and Event | - |
| Event Trigger | Motion detection, I/O alarm, Disk alarm, VCA alarm, Temperature alarm |
| Event Action | 'Event noti cation via audio clip, digital output, email, FTP, SD card |
| General | - |
| Connectors | RJ-45 cable connector for 10/100 Mbps Network/PoE connection Audio input Audio output DC 12V power input AC 24V power input Digital input *2 Digital output *2 BNC RS485 |
| LED Indicator | System power and status indicator |
| Power Input | AC 24V, DC 12V, IEEE 802.3af PoE Class 2 |
| Power Consumption | Max. 5W |
| Dimensions | ø141.8 x 367.4 mm |
| Weight | 2350g |
| Certi cations | EMC: CE (EN 55032, Class B), FCC (FCC Part 15 Subpart B), UKCA (BS EN 55032 Class B) Environment: IP66 |
| Operating Temperature | Working Temperature: -40°C ~ 60°C (-40°F ~ 140°F) |
| Humidity | 90% |
| System Requirements | - |
| Operating System | Microsoft Windows 10/8/7 Mac 10.12 (Chrome only) |
| Web Browser | Chrome 58.0 or above Internet Explorer 10/11 |
| Other Players | VLC: 1.1.11 or above |
| Temperature Measurement | - |
| Temperature Range | -20°C to 150°C (-4°F to 302°F) |
| Measurement Rule | Point, line, polygon (up to 20 rules in total) |
| Temperature Alarm | Threshold alarm, Temperature difference alarm, Temperature rise alarm, Section alarm |
| Accuracy | ± 2°C / ±2% |
| Included Accessories | - |
| Packing Contents | Quick installation guide, alignment sticker, screw pack, waterproof accessory bag, junction box, sunshield |
