Wi-Tek - WI-AP219AX - Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 1148Mbps on 2.4 GHz and 2402Mbps on 5 GHz totals 3550Mbps Wi-Fi speeds
Part number:
WI-AP219AX
Price:

Wi-Tek Wi-Fi 6 wireless ceiling AP series is specially designed for indoor Wi-Fi coverage. Support 802.3 PoE power supply, local power supply 12V DC. The dual network port design is conducive to the expansion of thirdparty devices and meets the needs of more networking scenarios. Compatible with 802.11a/b/g/n/ac/ax Wi-Fi protocol, 802.11ax protocol adopts OFDMA, 1024QAM, MU-MIMO, and other key technologies to support faster speed and more user access. In addition, the AP supports cloud management, and users can quickly deploy, configure, remotely manage and operate network-wide equipment, greatly reducing equipment investment costs. Offers fast wireless roaming and wired connectivity, ideal for use in hotels, retail, offices, and more.



Features:

  • Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 1148Mbps on 2.4 GHz and 2402Mbps on 5 GHz totals 3550Mbps Wi-Fi speeds
  • OFDMA and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously
  • Atheros chipset 1024MB DDR3, 256MB Flash, 500mW High-Power,access 500users
  • 48V PoE Support,2 x 2.5Gbps Port, not include PoE adapter
  • Support QVLAN+SSID, Portal,AC controller Managed and  Cloud Managed

Technical Specs

Wireless StandardsIEEE 802.11ax/ac wave2/wave1/n/b/g/a
Operating Bands2.4GHz & 5GHz
Antenna2.4Ghz:3dBi, 5GHz: 3dBi
Signal RateUp to 1148Mbps at 2.4GHz Up to 2402Mbps at 5GHz
Maximum Transmit Power<20dbm
Interface(2)10/100/1000M Base-T Ethernet ports
Power SupplyDC 12V/2A (Not Included) 802.3at PoE Supported
Power Consumption<22W
InstallationWall Mounting
External Buttonsreset button (long press for 8 seconds to restore the factory default co nfiguration)
Dimensions198mm * 198mm * 41mm
EnvironmentOperating Temperature:-20℃~55℃
Storage Temperature: Storage Temperature: -40°C~70 °C(non-condensing)
Humidity:5% ~95% (non-condensing)
Name
Description
Size
Downloads
File
Datasheet
0.5mb
