WI-IOTBOX02

Wi-Tek's Smart IoT Box is an all-weather outdoor electrical equipment protection box designed for outdoor use in the outdoor environment. It has waterproof, dustproof, heat dissipation, anti-ultraviolet, anti-theft, anti-rust, acid and alkali corrosion, anti-electromagnetic interference (anti-lightning EMP), modular structure design in the box, electrical equipment can be installed vertically or horizontally according to the situation. Work with Wi-Tek Industrial Switch,4G Cat6 LTE CPE, Solar UPS PoE Switch, Industrial IoT M2M Gateway, and Mesh AP can fit your CCTV/WLAN Wi-Fi Coverage/Industrial IoT Application requirements. Flexible modular installation can decrease your project deployment cost.

Features:

• Housing IP66 and IK08 Deisgn
• 1.2mm thickness 430 Stainless Steel Material
• Included Wall mounting and Pole mounting kits
• Included 2 mounting plate with DIN rails for customer equipment
• Included DIN Railcircuit breaker*1pcs,DIN Rail AC Socket*1pcs
• Waterproof Port connectors*4pcs for RJ45 and AC cable
• IPC/Wireless AP mounting hole cover*4pcs
• Operating Temperature: -40 ~ 80°C; Dimensions: 400x600x250mm, 12.3kg
• Multiple use for Junction, Distribution, Electrical, Battery, Control, Monitoring etc. Outdoor waterproof Enclosure Box，IPC/Wireless AP mounting hole
