Wi-Tek - WI-LTE300 V2 - 4G LTE Wireless Router

Product Overview

The Wi-Tek WI-LTE300 V2 is a Wi-Fi 4G LTE router designed to provide primary or backup internet connectivity through LTE and wired WAN access. It features an integrated LTE Cat.4 modem with up to 150Mbps download and 50Mbps upload speeds, 2.4GHz Wi-Fi up to 300Mbps, one 10/100Mbps WAN port, one 10/100Mbps LAN port, SIM card support, external 4G antennas, and Wi-Tek Cloud remote management.

Key Configuration

Model: WI-LTE300 V2 | Product Type: Wi-Fi 4G LTE Router | LTE Modem: Cat.4, up to 150Mbps download / 50Mbps upload | Wi-Fi Speed: Up to 300Mbps at 2.4GHz | Wi-Fi Standard: IEEE 802.11b/g/n | Channel Width: 20/40MHz | Ports: 1 x 10/100Mbps WAN, 1 x 10/100Mbps LAN | SIM Support: 1 SIM card slot | Antennas: Built-in 5dBi Wi-Fi antenna, 4 external 5dBi 4G antennas | Memory: 8MB RAM + 2MB Flash | VPN: OpenVPN Client | Power: DC 12V / 1A, up to 10W | Protection: ESD up to ±8kV air discharge / ±4kV contact discharge | Management: Web interface, Wi-Tek Cloud

Key Features

 · Integrated LTE Cat.4 modem supports up to 150Mbps download and 50Mbps upload speeds

 · Shares 4G LTE internet access with multiple Wi-Fi devices

 · 2.4GHz Wi-Fi supports wireless speeds up to 300Mbps

 · Supports IEEE 802.11b/g/n wireless standards

 · Includes one 10/100Mbps RJ45 WAN port and one 10/100Mbps RJ45 LAN port

 · Supports LTE FDD, LTE TDD, WCDMA, and GSM frequency bands

 · Includes one SIM card slot for mobile network access

 · External 5dBi 4G antennas and built-in 5dBi Wi-Fi antenna support wireless connectivity

 · Fail-over and Network Backup help maintain internet access if the primary link fails

 · OpenVPN client support enables encrypted VPN connectivity

 · Dynamic DNS support helps maintain access when the home IP address changes

 · Local web management and Wi-Tek Cloud remote management support flexible administration

 · DC 12V / 1A power input supports up to 10W power consumption

 · Built-in ESD protection supports up to ±8kV air discharge and ±4kV contact discharge

Technical Context

The WI-LTE300 V2 is intended for locations where wired internet is weak, unavailable, or requires LTE backup. It can operate as a primary 4G LTE router for homes, remote sites, and small networks, or as a backup router that automatically switches to 4G when the WAN connection fails.

Support for OpenVPN, DDNS, cloud management, multiple LTE/WCDMA/GSM bands, and fail-over operation makes the router useful for stable remote access, backup internet, and simple network deployment across residential and small business environments.

Installation Notes

Install a compatible SIM card and confirm mobile carrier band support before deployment. When using WAN fail-over, connect the wired internet source to the WAN port and configure the 4G LTE connection as backup according to the desired network priority.
