Wi-Tek - WI-PS210G-O V2 - Outdoor Weatherproof PoE Switch
(6FE+2GE)PoE+2GE+1SFP Uplink Outdoor PoE Switch with 8Port PoE Port
Features:
- (6FE+2GE)PoE+2GE+1SFP Uplink Outdoor PoE Switch with 8Port PoE Port
- IP65 Weatherproof enclosure, -30 ～70℃ working temperature
- Port 1-6 supports PoE IEEE 802.3af/at 30W for compliant PDs, Port 7-8 support
- 802.3bt 60W PoE Output
- All-in-one for easy installation
- Supports PoE IEEE802.3 af/at 30W for compliant PDs
- 120W Internal Power / 6KV PoE Surge Protection
- 10KV AC Surge Protection and IP65 Waterproof
Products | WI-PS210G-O |
Hardware Features | |
Hardware Version | V2 |
Interface | 6 10/100Mbps RJ45 PoE Ports 2 100/1000Mbps RJ45 PoE Ports 2 100/1000Mbps Uplink Ports 1 100/1000Mbps SFP Slot |
PoE Ports | Port 1-6: 802.3af/at Port 7- 8: 802.3 bt 60W |
Network Media | 10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) 1000BASE-TX: 6 Category and above UTP(≤150m) |
Power Supply | AC 110~240V 50/60HZ |
Power Budget | 120W |
Exchange Capacity | 11.2Gbps |
Packet Forwarding Rate | 8.33Mpps |
Mac Address Table | 4k |
Protection | 6kV PoE Surge Protection 10kV AC Surge Protection |
Jumbo Frame | 10240Bytes |
SOFTWARE FEATURES | |
Advanced Functions | Mac Address Auto-Learning And Auto-Aging Store and forward IEEE 802.3x flow control for Full-duplex Mode Backpressure for Half-duplex Mode |
OTHERS | |
Certification | CE, FCC, RoHS |
Package Dimension | 340×315×120 mm |
Switch Dimension | 350×255×90 mm |
Gross Weight | 1.95kg |
Net Weight | 1.4kg |
Package Contents | 1 × PoE Switch 1 × Power cord 1 × Quick Installation Guide 1 × Wall mounting KIT 1 × Pole mounting KIT 6 × Screws |
Environment | Working Temperature: -30℃ ~70℃(22℉~158 ℉) Storage Temperature: -40℃~70 ℃ (-40~158 ℉) Operating Humidity: 10~90% RH non-condensing Storage Humidity: 5~90% RH non-condensing |
