Wi-Tek Outdoor PoE Switch is a great solution for installers and customers, who now no longer have to order separate parts and assemble them into an outdoor enclosure box. Wi-Tek Outdoor PoE Switch comes with IP65 weather proof, 6kV surge protection, enabling your clients can be working in harsh environment with high performance. Wi-Tek Outdoor Waterproof 802.3af/at PoE Switch Series IP65 gigabit PoE switch featured is designed for industrial and commercial applications, e.g., video surveillance, remote security, commercial Wi-Fi installations
Features:
- 8 10/100/1000Mbps RJ45 PoE Ports
- 2 100/1000Mbps Uplink Ports
- 2 100/1000Mbps SFP Slots
- IP65 weatherproof enclosure
- Working Temperature: -30 ～70℃
- All-in-one for easy installation
| Products | WI-PS310GF-O |
| Hardware Features | |
| Hardware Version | V1 |
| Interface | 8 10/100/1000Mbps RJ45 PoE Ports |
| 2 100/1000Mbps Uplink Ports | |
| 2 100/1000Mbps SFP Slots | |
| PoE Ports | Port 1- 6: 802.3af/at |
| PoE Ports: Port 7- 8 802.3 bt 60W | |
| Network Media | 10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) |
| 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) | |
| 1000BASE-TX: 6 Category and above UTP(≤150m) | |
| Power Supply | AC 110~240V 50/60HZ |
| Power Budget | 120W |
| Exchange Capacity | 24Gbps |
| Packet Forwarding Rate | 17.37Mpps |
| Mac Address Table | 8k |
| Protection | 6kV PoE Surge Protection |
| 10kV AC Surge Protection | |
| Jumbo Frame | 10240Bytes |
| SOFTWARE FEATURES | |
| Advanced Functions | Mac Address Auto-Learning And Auto-Aging |
| Store and forward | |
| IEEE 802.3x flow control for Full-duplex Mode | |
| Backpressure for Half-duplex Mode | |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Dimension | 340×315×120 mm |
| Switch Dimension | 350×255×90 mm |
| Gross Weight | 1.95kg |
| Net Weight | 1.4kg |
| Package Contents | 1 × PoE Switch |
| 1 × Power cord | |
| 1 × Quick Installation Guide | |
| 1 × Wall mounting KIT | |
| 1 × Pole mounting KIT | |
| 6 × Screws | |
| Environment | Working Temperature: -30℃ ~70℃(22℉~158℉) |
| Storage Temperature: -40℃~70℃ (-40~158℉) | |
| Operating Humidity: 10~90% RH non-condensing | |
| Storage Humidity: 5~90% RH non-condensing | |
Name
Description
Size
Downloads
File
Data Sheet
0.5mb
File
Quick Guide
1.5mb
