Wi-Tek - WI-SFP10L-3KM-I - Industrial SFP Module

Product Overview

WI-SFP10L-3KM-I is an industrial 1.25 Gbps SFP optical transceiver designed to extend network connections over single-mode fiber up to 3 km. It uses a simplex LC connector, supports bidirectional wavelength options, and includes Digital Diagnostic Monitoring for reliable operation from -40°C to 85°C.

Key Configuration

Model: WI-SFP10L-3KM-I | Data Rate: 1.25 Gbps | Maximum Cable Length: 3 km | Fiber: Single-mode | Connector: Simplex LC | Wavelength Options: A Tx1310/Rx1550 nm, B Tx1550/Rx1310 nm | Power Supply: 3.3 V | Power Consumption: 1 W max

Key Features

• · Supports 1.25 Gbps data transmission
• · Extends single-mode fiber links up to 3 km
• · Uses a simplex LC optical connector
• · Supports wavelength option A: Tx1310 nm/Rx1550 nm
• · Supports wavelength option B: Tx1550 nm/Rx1310 nm
• · Uses an FP transmitter and PIN/TIA receiver
• · Provides transmitter power of -9 to -3 dBm and receiver sensitivity below -21 dBm
• · Supports Digital Diagnostic Monitoring (DDM)
• · Supports SFP MSA, MSA SFF-8472, and IEEE 802.3ah compatibility
• · Supports operation from -40°C to 85°C with 10%-90% non-condensing humidity

Technical Context

The simplex transceiver uses bidirectional wavelength options to transmit and receive data over a single optical fiber, reducing fiber-pair requirements for medium-distance links. Its 1.25 Gbps capacity, 3 km reach, and DDM support provide reliable fiber connectivity with monitoring of key operating parameters in compatible SFP equipment.

Installation Notes

Insert the module into a compatible SFP slot and connect the simplex LC fiber to the matching optical module at the remote end. Select matching A/B wavelength versions for the link and use single-mode fiber. The module is hot-pluggable and supports plug-and-play operation without additional configuration.
