Vivotek - AO-20W - Wiegand Convertor for IB9387-LPR, IB9365-LPR
Part number:
AO-20W
Price:
Wiegand Convertor for IB9387-LPR, IB9365-LPR.
Features:
- Easy Integration into any Access Control System
- Use in Combination with the ANPR Access Service
- Supports Ethernet to Wiegand Output Conversion
- Supports 26-bit and 34-bit Wiegand Format
| Technical Specification | |
| Product Information | |
| Model | AO-20W |
| Hardware | |
| TCP Server | 10/100 Mbps Base T Ethernet <--> RS485 |
| (Auto-detection by order: RS232, RS232+RS485) | |
| Server Port 0 | Baud rate: 2400 bps - 115200 bps |
| Support TCP/Server, TCP/Client, UDP mode | |
| Server Port 1 | Baud rate: 2400 bps - 115200 bps |
| Support TCP/Server, TCP/Client, UDP mode | |
| Maximum Wiegand Output | Up to 96 bits |
| PoE | No |
| General | |
| Connectors | Digital input x 8 |
| Digital output x 4: relay output x1 & digital output x3 | |
| (DO1, DO2 = WG data 1, data 0 when using Wiegand protocol) | |
| LED Indicator | 9 LEDs for power, communication |
| Power Input | DC 9 ~ 24V |
| Power Consumption | Max. 2W |
| Dimension | 106.5 (L) x 66.3 (W) x 27.7 (H) mm |
| Weight | 86 (±5) g |
| Safety Certifications | FCC, CE, RoHs |
| Operating Temperature | Starting Temperature: -25°C ~ 85°C (14°F ~ 185°F) |
| Working Temperature: -20°C ~ 65°C (-4°F ~ 149°F) | |
| Humidity | Storage: 5% ~ 95% |
| Working: 20% ~ 90% | |
| Buffer | 1K each channel |
| Surge Protection | Power: 30 Volt, bi-directional avalanche breakdown device |
| RS485 6.5 Volt, bi-directional avalanche breakdown device | |
| 400W peak power dissipation | |
| Clamping time < 1 picosecond (theoretical) | |
| Fuse Protection | Power PTC 150mA / RS485 PTC 30mA |
| Software | |
| Software Setting | 701Server, 701Client HTTP web browser |
| Operating System | Windows 7/8/10 |
| Win Server 2008/2012/2016 | |
| Watchdogs | Yes, build in watchdog for system error handling |
