SECO-LARM - SK-919TP4H-NQ - 4-Button, 15-Channel Handheld RF Transmitter
Part number:
SK-919TP4H-NQ
Price:

Make access control, security, home automation, gate operation, or any type of product wireless with RF transmitters and receivers from SECO-LARM. Regardless of project, SECO-LARM RF equipment is a profitable, easy-to-install add-on for any application.



Features:

  • Extreme durability – rubber buttons eliminate damage caused by electrostatic discharge and help make transmitter weatherproof (IP65). Gold-plated battery clips and contact points extend the life of the transmitter
  • Magic LED only appears when buttons are pressed
  • 315MHz Operating frequency (433.92MHz. also available  by request)
  • Over 68 billion possible codes
  • CODEBUMP models also available with 18 quintillion possible codes
  • RF anti-scan protection
  • Includes two 3VDC lithium batteries
  • Compatible with all 315MHz SECO-LARM receivers
  • Visor clip and belt clip included. Belt-clip holster & wall-mount bracket also available (Model SK-9HBC)

*Actual range will vary greatly depending on the installation and operating environment

Type4-Button, 15-Channel
RF Frequency315MHz
No. of Buttons4
Channels15
IP RatingWeatherproof IP65
No. of Codes68 billion possible codes
Dimensions3 -1/2” x 2-3/16” x 1/2” (89 x 56 x 12 mm)
