• 4096 x 1860 Resolution at 20 fps
• Super Wide Angle
• IP67- and IK10-Rated for Outdoor Use
• RJ45 Ethernet with PoE Technology
• Deep Learning AI
• Inputs and Outputs for 2-Way Audio
| Key Specs | |
|---|---|
| Image Sensor | 1/2.7"-Type CMOS |
| Focal Length | 4mm |
| Pan/Tilt | Programmed Pan: 360° (0 to 360°) Tilt: 75° (0 to 75°) |
| Built-In Microphone | Stereo |
| Power I/O | 1x DC 1x RJ45 |
| Imaging | |
| Number of Lenses | 2 |
| Image Sensor | 1/2.7"-Type CMOS |
| Sensor Resolution | Effective: 8 Megapixel |
| IR Cut Filter | No |
| Day/Night | No |
| Exposure Control | |
| Shutter Speed | 1/100000 to 1 Seconds |
| Automatic Gain Control | No |
| Signal-to-Noise Ratio | 75 dB |
| Minimum Illumination | 0.0005 Lux (Color) |
| Lens | |
| Focal Length | 4mm |
| Maximum Aperture | f/1 |
| Video | |
| Max IP Streaming | via RJ45 4096 x 1856 up to 20 fps 1280 x 576 up to 20 fps |
| Multi-View Streaming | Yes: 2 Streams |
| Control | |
| Camera Angle Adjustment | Horizontal: 0 to 180° Vertical: 0 to 47.41° |
| Pan/Tilt | Programmed Pan: 360° (0 to 360°) Tilt: 75° (0 to 75°) |
| Interface | |
| Audio I/O | 1x Block Input 1x Block Output |
| Other I/O | 1x RJ45 |
| 1- or 2-Way Audio | Two-Way |
| Audio Formats | G.711 |
| Built-In Microphone | Stereo |
| Built-In Speaker | Yes |
| External Storage Options | No |
| System Integration | |
| Built-In Installation Aids | No |
| Sensors & Alarms | |
| Event Trigger | No |
| Alarm I/O | No |
| Power | |
| PoE Support | PoE 802.3af |
| Power I/O | 1x DC 1x RJ45 |
| Power Consumption | PoE: 12 VDC |
| Environmental | |
| Operating Conditions | -22 to 140°F / -30 to 60°C |
| Impact Resistance | Impact-Resistant (IK10) |
| Environmental Resistance | Dust/Water-Resistant (IP67) |
| General | |
| Materials | Metal |
| Certifications | CE, FCC |
| Illumination | IR LEDs up to 98.4' / 30 m |
