The NS-2 is Akuvox 2-wire IP network switch which provides a convenient way to upgrade analogue intercom systems, no need for rewiring. Its super long transmission distance & good compatibility with existing lines makes it fit for most of old buildings.
Features:
- Support network and power supply for R20A-2 or C313W-2 through 2-wire cable
- Support multi-level cascade through 2-wire cable
- Connects up to 6 pcs of Akuvox 2-wire IP intercom devices
- Super long transmission distance via 2-wire cable
- Powerd by 48VDC or 24VDC power supply unit
- Rail mounting installation
| Specifications | |
| Physical & Power | Communication: TCP/IP RJ45 port: 1 x RJ45 port, 10/100Mbps adapter 2-wire ports: 6 pair Working voltage: 48V or 24V Status Indicator: 4 Installation: Rail mounting Working temperature: -20℃~+50℃ Storage temperature: -20℃~+70℃ Working humidity: 10%~90% Dimension: 161 x 90 x 65 (mm) Old building retrofit |
