Digital Watchdog - DW-BJAiMT36T - Blackjack AI mid-Tower, Windows OS on SSD, 4 DW Spectrum Recording Licenses and 4 IVA Ai Server Licenses 36TB
Part number:
DW-BJAiMT36T
Price:

Blackjack AI mid-tower, Windows OS on SSD, 4 DW Spectrum recording licenses and 4 IVA Ai Server licenses pre-installed,64 cameras @ 2.1MP, 64 analytic streams, 480Mbps throughput, Intel i7, 32GB RAM, 36TB storage, 5 Year Limited Warranty



Blackjack Ai Tower Artificial Intelligence Network Video Recorder (Ai NVR) is a purpose-built server, with built-in server-side analytics that unlock advanced Ai capabilities on any connected video stream via our DW Ai Server software. This cost-effective, plug-and-play appliance combines high-performance recording with video analytics in an easy-todeploy turnkey solution. The NDAA and TAA compliant server features up to 320Mbps throughput, 64 secondary streams and comes preloaded with DW Spectrum IPVMS, with four complimentary recording licenses. Add the power of advanced neural-network-based analytics to your video streams with a Blackjack Ai NVR, backed by our 5 year limited warranty.



Features:

  • Hosting DW Ai software deep learning and color filter
  • Server-side analytics for non-analytic cameras
  • Deep learning classifiers and logical rules engine
  • A single device for NVR and Analytics server for lower deployment cost
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 320Mbps throughput
  • Up to 64 analytic streams
  • Supports all ONVIF conformant IP cameras
  • 16-48TB internal storage
  • 12th Gen Intel Core i7 processor
  • Mini Display Port local output for system configuration
  • Dual network ports
  • Windows 10 on SSD
  • Hosting DW Spectrum for setup, configuration, monitoring and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) 4-channel recording license included (DW-SPECTRUMLSC004)
  • One (1) 4-channel Ai license included (DW-IVAAiSERVERLSC004)
  • No annual maintenance fees
VIDEO
CPUIntel Core i7 processor
Display ModesUnlimited, Customizable, Sequence
Local Video Outputs1x mini Display Port, For initial configuration and server management
Memory32GB
Video CardNVIDIA RTX A2000 12GB
Video CompressionH.264, H.265
Video Operating SystemWindows 10 IoT Enterprise LTSC
OS on SSD480GB SSD
Max throughput (Mbps)320Mbps
STORAGE
Raw internal storage options024TB036TB048TB
RAID OptionsNo RAID
Max HDD Bay3 x SATA HDD
Maximum Storage16TB (DW-BJAiMT16T), 24TB (DW-BJAiMT24T), 36TB (DW-BJAiMT36T), 48TB (DW-BJAiMT48T)
PERFORMANCE
Max # of analytic streams (secondary)Up to 64
Performance featuresA single device for NVR and Analytics server for lower deployment cost, Deep learning classifiers and logical rules engine, Server-side analytics for non-analytic cameras
Playback FunctionsCalendar, Event search, Smart motion search, Thumbnail search, Timeline
PTZ controlONVIF
Recording ModesContinuous, Motion + low res always, Motion + Object, Motion + Object + Low res, Motion detection, Object + Low res, Object only
System OperationGraphical user interface (GUI), Remote via DW Spectrum IPVMS, USB mouse (included)
NETWORK
BackupNetwork backup via DW Spectrum IPVMS
Ethernet Ports2x 1G Ethernet (RJ45)
Pre-loaded VMS softwareDW Spectrum IPVMS
Network Remote SoftwareCross-platform - Windows, Linux Ubuntu and Mac, DW Mobile Plus, DW Spectrum Mobile App
ELECTRICAL
Power Consumption500W, A UPS is recommended
GENERAL
AccessoriesKeyboard, Mouse
Ai Configuration Tool supported OSCross-platform - Windows and Linux Ubuntu
Included DW Ai Server Licenses4 channel (DW-DWAiSLSC004)
Included IP licenses4
Operating Temperature and Humidity20 ~ 90% RH, 41 ~ 104 °F (5~40 °C)
Preloaded Analytic softwareDW Ai Server
Recorder Dimensions (H X W X D)7.46” x 15.7” x 14.21” (189.52 x 398.8 x 631.02 mm)
Recording Licenses (Optional. Sold Separately)Custom-ordered licenses are available by request.
DW-SPCP04LSC004 - Four (4) DW Spectrum Analog Encoder IPVMS Licenses
DW-SPCP16LSC016 - Sixteen (16) DW Spectrum Analog Encoder IPVMS Licenses
DW-SPECTRUMLSC001 - Single DW Spectrum IPVMS Recording License
DW-SPECTRUMLSC004 - Four (4) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC010 - Ten (10) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum IPVMS Recording Licenses
DW-SPIOLSC001 - Single DW Spectrum I/O Module IPVMS License
DW-SPVWALL1X2 - Single DW Spectrum Video Wall IPVMS License
Lifetime upgrades are included with no annual renewal fees.
USB interfaceYes
Warranty5 Year Limited Warranty
Weight (barebone, HDD not included)11.8 lbs (5.35 kg)
CertificationCEFCCNDAA ComplianceONVIF ConformantTAA Compliance
Form FactorMid-size Tower
