Digital Watchdog - DWC-MF21M28T - MEGApix 2.1MP/1080p ultra low-profile vandal dome IP camera with 2.8mm fixed lens
Part number:
DWC-MF21M28T
Price:
The MF21M28T MEGApix camera is a dual codec Surface Mount Outdoor Dome network camera that provides 1080P megapixel resolution at 30 frames per second. The camera’s advanced technologies such as True Day and Night, 3D-DNR and WDR will deliver the best images in any type of environment. Power over Ethernet will simplify installation by connecting both power and network through a single cable. Housed in our attractive vandal-resistant aluminum die-cast dome enclosure.
Features:
- 2.1MP/1080p 1/2.7" image sensor at real-time 30fps
- 2.8mm fixed lens
- True Wide Dynamic Range (WDR)
- Dual codecs (H.264, MJPEG) with simultaneous streaming
- Ultra low-profile vandal dome camera housing
- Smart DNR 3D digital noise reduction
- True day/night mechanical IR cut filter
- Programmable privacy zones
- Auto gain control (AGC)
- Auto white balance (AWB)
- Motion detection
- Micro SD/SDHC/SDXC class 10 card slot (card not included)
- Web server built-in
- PoE class 2 and DC12V
- ONVIF conformant, profile S
- NDAA/TAA compliant
- IP66 environmental-rated dust-tight and water-resistant
- IK 10-rated impact-resistant
- 5 year warranty
IMAGE | ||
| Image sensor | 2.1MP/1080p 1/2.7“ CMOS | |
| Total pixels | 1928 (H) x 1088 (V) | |
| Minimum scene illumination | 0.25 lux (color) | |
| Video output | Local video output CVBS 1.0V p-p (75?), 4:3 aspect ratio | |
LENS | ||
| Focal length | 2.8mm F2.0 | |
| Lens type | Fixed lens | |
| Field of view (FoV) | 118° | |
| IR distance | 30ft range | |
OPERATIONAL | ||
| Shutter mode | Auto, manual, anti-flicker, slow shutter | |
| Shutter speed | 1/30 ~ 1/8000 | |
| Slow shutter | 1~1/5,1/7.5, 1/15 | |
| Auto gain control | Auto | |
| Day and night | Auto, day (color), night (B/W) | |
| Smart DNR™ 3D digital noise reduction | 0 ~ 11 | |
| Wide dynamic range (WDR) | True WDR, on, off | |
| Wide dynamic range (WDR) dB | 120dB | |
| Privacy zone | 16 programmable privacy masks | |
| Backlight compensation (BLC) | On / off / HSBLC | |
| Mirror and flip | Yes | |
| Alarm notifications | Notifications via e-mail, FTP server or SD card recording | |
| Memory slot | Micro SD / SDHC / SDXC up to 128GB (card not Included) | |
NETWORK | ||
| LAN | 802.3 compliance 10/100 LAN | |
| Video compression type | H.264, MJPEG | |
| Resolution | H.264: 1080p/720p/VGA/D1/CIF MJPEG: 1280 x 720/800 x 600/VGA/768 x 432/D1/CIF | |
| Frame rate | Up to 30fps at all resolutions | |
| Video bitrate | 100Kbps ~ 10Mbps, Multi-rate for preview and recording | |
| Bitrate control | Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth) | |
| Streaming capability | Dual-stream at different rates and resolutions | |
| IP | IPv4 | |
| Protocol | ONVIF, TCP/IP, UDP, autoIP, RTP(UDP/TCP), RTSP, NTP, HTTP,HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2c/v3(MIB-2) | |
| Security | HTTPS(TLS), IP filtering, 802.1x, digest authentication (ID/PW) | |
| ONVIF conformance | Yes | |
| Web viewer | OS: Windows®, Mac® OS, Linux® | |
| Browser: Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari® | ||
| Video management software | DW Spectrum® IPVMS | |
ENVIRONMENTAL | ||
| Operating temperature | -4°F ~ 122°F (-20°C ~ 50°C) | |
| Operating humidity | Less than 90% (non-condensing) | |
| IK rating | IK10 impact resistant | |
| IP rating | IP66 certified weather and tamper resistant | |
| Other certifications | CE, FCC, RoHS | |
ELECTRICAL | ||
| Power requirement | DC 12V, PoE (IEEE 802.3af Class 3). (adaptor not included) | |
| Power consumption | DC12V: max 5.2W PoE: max 7.1W | |
MECHANICAL | ||
| Material | Aluminum vandal housing, polycarbonate dome | |
| Dimensions | 4.9" x 2.9" (125 x 74.3 mm) | |
| Weight | 1.54 lbs (0.7kg) | |
