Hanwha - HV-IE220-6GHX-K90 - 4 x Gigabit Ethernet PoE++ 180W Industrial Rugged Switch
Part number:
Price:
The Hanwha HV-IE220-6GHX-K90 is a compact, ultra-high-power industrial Layer 2 managed switch, equivalent to the Allied Telesis IE220 series. It has been specifically engineered for 'edge' deployments where a small number of high-draw devices, such as multi-sensor cameras or heavy-duty PTZs, require PoE++ up to 90 W in extreme environmental conditions.
| Network Switch Specifications | |
|---|---|
| 10/100/1000T Copper Ports | 4 |
| 1/10G SFP+ Ports | 2 |
| Total Ports | 6 |
| PoE Enabled Ports | 4 |
| Switching Fabric | 48 Gbps |
| Forwarding Rate | 35.7 Mpps |
| Input Voltage | 37~57V DC |
| Non PoE+ Load | |
| Max Power Consumption (W) | 17.4 |
| Max Heat Dissipation (BTU/H) | 59.5 |
| Max Noise (dBA) | Fanless |
| Full PoE+ Load | |
| Max Power Consumption (W) | 204 |
| Max Heat Dissipation (BTU/H) | 80.3 |
| Max Noise (dBA) | Fanless |
| Total PoE Power Budget (W) | 180 |
| PoE Sourcing Ports | PoE+ (30W): 4, PoE++ (60W): 2, PoE+++ (90W): 2 |
| Physical Characteristics | |
| Width / Depth / Height | 65 x 137 x 155 mm (2.56 x 5.39 x 6.12 in) |
| Weight | Din rail: 1.57 kg (3.46 lb), Wall mount: 1.45 kg (3.20 lb) |
| Enclosure | Aluminium, Sheet Metal Shell |
| Protection Rate | IP30 |
| Port Speed Latency | 100 Mbps: 12.02 µs, 1 Gbps: 2.81 µs, 10 Gbps: 2.31 µs |
