Hanwha - HV-X530L-18GHXM-90 - 16 x Gigabit Ethernet PoE++ 720W
Part number:
Price:
• 8/16/24/48 ports, with 2/4 uplinks
• 520/740W PoE+/PoE++ power budget
• Fully managed
• AW+ OS (CLI, GUI and NetCONF/RESTCONF)
• SFP+ support 1Gbps and 10Gbps
• Active fiber monitoring
• Static and multicast routing
• Tri-authentication: MAC-based, Web-based and IEEE 802.1x
• QoS classification
• Virtual Chassis Stack (up to 8)
• EPSR Master or Transit
| Ports & Performance | |
|---|---|
| 10/100/1000T Copper Ports | 16 |
| 100M/1/2.5/5 Gigabit Ports | 16 |
| 1/10G SFP+ Ports | 2 |
| Total Ports | 18 |
| PoE+ Enabled Ports | 16 |
| Switching Fabric | 200 Gbps |
| Forwarding Rate | 148.8 Mpps |
| Non PoE+ Load | |
| Max Power Consumption (W) | 86 |
| Max Heat Dissipation (BTU/H) | 293 |
| Max Noise (dBA) | 42 |
| Full PoE+ Load | |
| Max Power Consumption (W) | 970 |
| Max Heat Dissipation (BTU/H) | 3317 |
| Max Noise (dBA) | 42 |
| Total PoE Power Budget (W) | 720 |
| PoE Sourcing Ports | PoE (7.5W): 16, PoE (15.4W): 16, PoE+ (30W): 16, PoE++ (60W): 12, PoE++ (90W): 8 |
| Physical Characteristics | |
| Height | 44 mm (1.73 in) |
| Width | 441 mm (17.36 in) |
| Depth | 256 mm (10.07 in) |
| Weight | 4.3 kg (9.48 lb) |
| Port Speed Latency | |
| 100 Mbps | 8.35 µs |
| 1 Gbps | 7.96 µs |
| 2.5 Gbps | 7.72 µs |
| 5 Gbps | 5.23 µs |
| 10 Gbps | 2.56 µs |
