CDI2530PZ - 2MP DirectNET Outdoor PTZ Dome Camera - IDIS
• 2 megapixel resolution (1080p)
• IP Pan Tilt Zoom with 30x auto focus lens
• 1/3” CMOS Progressive Scan image sensor
• True day/night with IR cut filter
• DirectNET protocol, iNEX™ protocol selectable
• Micro SD memory card supported (32GB)
• Back Light Compensation (BLC)
• Digital Noise Reduction (DNR)
• Auto Tracking
• True Wide Dynamic Range (TWDR)120db
• Multiple compression (H.265,H.264, MJPEG)
• IP66 weatherproof rated
• IK10 vandal resistant housing
• Heater included
• Power over Ethernet (PoE+), 24VAC
| Power | |
|---|---|
| Source | PoE+, 24VAC |
| PoE | 802.3at class 4 |
| Consumption | 12W (Heater Off) 15.3W (with heater) |
| Sensor | |
| Image Sensor | 1/2.8” CMOS |
| Scanning Mode | Progressive Scan |
| Resolution | 1920 x 1080 |
| Lens Type | Vari-focal |
| Lens Focal Length | f = 4.3 ~ 129.0 mm |
| Aperture | F = 1.6 - 5.0 |
| Iris | DC Auto iris |
| Minimum Illumination | Color: 0.16 Lux @ F1.6 |
| Frame Rate | Up to 60 fps |
| S/N Ratio | ≥ 45 dB |
| Dynamic Range | ≥ 120 dB |
| Minimum Object Distance | 3.28 feet (1.0 m) |
| Electronic Shutter | Auto / Manual: 1/30 ~ 1/8000 Anti-Flicker: Slow Shutter: 1/7.5, 1/15 |
| Viewing Angle | Wide: 71.8°D Tele: 2.6°D |
| Pan/Tilt Range | Pan: 360° continuous Tilt: 0.02° ~ 180° |
| Pan/Tilt Speed | Pan: 0.02° ~180° / sec. Tilt: 0.02° ~180° / sec. |
| Video | |
| Video Compression | H.265, H.264, MJPEG |
| Streaming | Quadruple Stream |
| Protocol | DirectNET, iNEX |
| External Storage | 32GB Micro SD Card |
| Audio Compression | G.726, G.711 |
| Camera | |
| Alarm | 1 In/ 1 Out |
| Audio | 1 In/ 1 Out |
| Auto Exposure | Yes |
| Auto White Balance | Yes |
| Back Light Compensation | Yes |
| Day/Night | with ICR |
| Digital Noise Reduction | Yes |
| Event Buffering | up to 60MB |
| Event Notification | Remote S/W, Email with images |
| Event Triggers | Face Detection Motion, Detection Tampering, Auto Tracking |
| Motion Detection | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Network | |
| Security | SSL Encryption |
| Remote Access Client | StarNET |
| Streaming Video | Quadruple Stream |
| Camera Protocol | DirectNET V1.0.0 or greater |
| Network Protocols | Zero Configuration |
| Security | Multi-user Authority, HTTPS, SSL Encryption |
| Remote Access Client | iNEX |
| Streaming Video | Quadruple Stream |
| Camera Protocol | ONVIF Profile S |
| Network Protocols | RTP/RTSP/TCP RTP/RTSP/HTTP/TCP RTP/UDP RTSP/TCP HTTP, HTTPS, FTP, SNMP, SMTP, FEN, mDNS, uPNP |
| General | |
| Temperature | -40°F to 140°F (-40°C to 60°C) |
| Humidity | 90% RH Max |
| Approvals | IP66, IK10, CE, FCC, KC, UL |
| Dimensions (Ø x H) | 7.9” x 7.9” (200 x 199.5 mm) |
| Weight | 5.40 lbs. (2.45 kg) |
| Accessories | |
| Accessories | CDMWM20 Wall Mount CDMPM20 Pendant Mount CDASS18 Sun Shield |
This is a high-performance 2-megapixel Full HD (1080p) outdoor PTZ dome camera. Its core feature is a powerful motorized vari-focal lens with an extraordinary zoom range from 4.3mm to 129.0mm (30x optical zoom), allowing it to view a wide area and then zoom in for extreme detail on distant subjects. It supports a high frame rate of up to 60 fps for smooth tracking.
For environmental durability, it features IK10 vandal resistance, IP66 weatherproofing, and a built-in heater, enabling operation in an extreme temperature range from -40°C to 60°C. It incorporates 120 dB Wide Dynamic Range (WDR) and supports advanced analytics like Auto Tracking and Face Detection. It provides standard audio and alarm I/O interfaces. The camera supports dual protocols (DirectNET for IDIS systems and iNEX/ONVIF for third-party integration) and quadruple video streaming. It can be powered by PoE+ (802.3at) or 24VAC, with a maximum power consumption of 15.3 watts when the heater is active.
