CR8020XDI-3TB - 8 Channel NVR H.264 and H.265 Linux OS - IDIS
- • 8 Channel Full-HD real-time recording
- • 8 Channel PoE switch built-in
- • Up to 36TB of internal storage
- • H.264 and H.265 codec compression
- • x2 ~x12 Digital Zoom
- • Two-way audio communication
- • Video Motion Detection (VMD)
- • Video Obscuration Detection (VOD)
- • 2 USB 2.0 ports and 1 USB 3.0 port
- • USB mouse operation (mouse not included)
- • Text interface for ATM applications
- • StarNET Video Management Software (VMS) included
- • StarNET Mobile free smart phone app compatible with Apple® and Android™ devices
| Model | CR8020XDI |
| Channels | 8 Channels |
| HDD Options | Up to 36TB Capacity |
| Power | |
| Source | AC 100-240 V |
| Consumption | Max. 200W (with 6 HDDs) |
| Video | |
| Camera Inputs | 8 IP Cameras |
| Monitor Outputs | 1 HDMI, 1 VGA |
| Display Resolutions | 3840x2160, 1920x1200, 1920x1080, 1680 x 1050, 1600 x 1200 |
| Display Speed | 8 Channels Up to 240ips |
| Digital Zoom Live | x2 ~ x12 |
| Live Display Throughput | 80Mbps |
| Recording | |
| Record Rate | 100Mbps, 240ips @ Full HD, 120ips @ 4K (UHD) |
| Compression | H.265, H.264 |
| Recording Modes | Time-lapse, Event, Pre-event, Panic |
| Event Triggers | Alarm In, Audio Detection, Motion Detection, Trip Zone Tampering, Video Loss |
| Playback | |
| Remote Playback Rate | 50 Mbps |
| Performance | 8ch Full HD synchronous playback, 4ch 4K synchronous playback |
| Search Modes | Event Log, Motion, Text-in, Time-lapse, Thumbnail |
| Digital Zoom Playback | x2 ~ x12 |
| Interface | |
| Audio In/Out | NVR: 1RCA/1RCA + 1HDMI, IP Camera: 8/8 (Depending on IP Camera) |
| Alarm In/Out | NVR: 4/1, IP Camera: 8/8 (Depending on IP Camera) |
| eSATA | 4 eSATA Ports |
| Serial Interface | RS232 (Terminal Block), RS485 (Terminal Block) |
| USB | USB 2.0 x 1, USB 3.0 x 1 |
| User Interface | Front Buttons, USB Mouse, IR Remote Control, Remote Keyboard |
| Network | |
| Operating System | Embedded Linux |
| Connection | Gigabit Ethernet (Client) x1 |
| Camera Power | PoE (IEEE 802.3at Class 4) Supported 8 Ports, 120 watts |
| Remote Data Export | AVI, JPG, Clip Copy |
| Event Notification | Email (Attach MP4), Callback to Remote S/W, Push Notification, SNS (Twitter) |
| Throughput Speed | 50Mbps (100 Mbps BRP On) |
| General | |
| Temperature | 32°F to 104°F (0°C to 40°C) |
| Humidity | 90% RH Max |
| Approvals | FCC, UL, CE, CB, KC |
| Weight | 13.2 lbs. (6.0 kg) with 1 HDD |
| Dimensions (WxHxD) | 16.9" x 3.5" x 16.2" (430 x 88 x 410.8 mm) |
| Storage | |
| HDD | SATA x6, eSATA x4, (Up to 6TB Capacity for Each Disk), RAID 1 supported |
| Total Capacity | 132TB=6TB x (6(Internal) + 4x4(External) |
| Data Export Device | USB HDD, USB Stick |
This is an 8-channel IP video recorder (NVR) with integrated 8-port PoE+ (IEEE 802.3at) switch functionality. It supports video display at resolutions up to 3840x2160 (4K UHD) via HDMI or VGA outputs, with a live display throughput of 80Mbps. Recording is handled at up to 100Mbps total throughput, supporting 240ips at Full HD or 120ips at 4K resolution using H.265 or H.264 compression. The unit offers 8-channel Full HD or 4-channel 4K synchronous playback.
Storage is supported by six internal SATA HDD bays and four eSATA ports for external expansion, with support for RAID 1. It operates on an embedded Linux system and consumes a maximum of 200W when populated with six HDDs. The device is designed for an operating temperature range of 0°C to 40°C and up to 90% humidity.
