DC-V4212XJ 2.4mm - 2MP Modular Covert Camera - IDIS
Part number:
Price:
- • Easy installation with DirectIP NVR
- • Full HD (1080p) resolution
- • Fixed-focal lens (f=2.4mm)
- • Micro SD/SDHC/SDXC
- • Two-way audio
- • Alarm in / out
- • PoE (IEEE 802.3af Class 4)
- • True wide dynamic range (WDR)
| Video | |
| Image Sensor | 1/2.8" CMOS |
| Max. Resolution | 1920 x 1080 |
| Scanning Mode | Progressive Scan |
| Lens Type | Fixed-focal |
| Focal Length | 2.4mm |
| Aperture | F2.0 |
| Iris Control | Fixed Iris |
| Angular Field of View | 132.5º(H), 72.7º(V), 154.7º(D) |
| Min. Illumination | COLOR : 0.1 lux @ F2.0 B/W : 0.01 lux @ F2.0 |
| Dynamic Range | More than 70 dB |
| Electronic Shutter Speed | Auto / Manual (1/30,1/25Sec ~ 1/30000Sec) / Anti-Flicker |
| Day and Night | Yes (Electrical) |
| IR Distance (LEDs) | - |
| Image Setting | Sharpness, 3DNR, Exposure |
| Backlight Compensation | BLC, WDR, HLC |
| Mirroring / Pivot | Horizontal / Vertical / Pivot |
| Image Stabilizer | - |
| De-fog | Yes |
| Privacy Masking | 8 Zones |
| Intelligent Video | Video Motion Detection, Active Tampering Alarm, Trip Zone |
| Video Out | - |
| Network | |
| Video Compression | H.265, H.264 (MP), M-JPEG |
| Intelligent Codec | Yes |
| Bitrate Control | H.264 - CBR / VBR, H.265 - CBR / VBR |
| Audio Compression | G.726, G.711 u-Law, G.711 a-Law |
| Two-way Audio | Yes |
| IP Camera Protocol | DirectIP 2.0 |
| Max. Frame Rate | 30ips : 1920 x 1080 (WDR) |
| Supported Resolution | 1920x1080, 1280x720, 640x360, 352x240 |
| Multi-video Streaming | Quadruple Streaming |
| Network Protocols | DirectIP 2.0 Protocol, IPv4, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, Upnp |
| Security | Digest authentication, Password Protection, User access log, IP Filtering, IEEE802.1x(EAP-TLS), Chained Fingerprint, SSL Encryption, HTTPS Encryption |
| Ethernet | RJ45 (10/100BASE-T) |
| Recording Session Buffer (NLTSrec) | Yes (Up to 60MB) |
| Edge Storage | micro SD/SDHC/SDXC, Smart Failover (Up to 512GB) |
| Alarm and Event | |
| Trigger Event | Motion Detection, Alarm in, Audio detection, Tampering, Trip Zone |
| Event Notification | Remote S/W, Email (with Image) |
| Audio Alarm | Yes |
| Audio In / Out | 1 / 1 |
| Alarm In / Out | 1 / 1 |
| Environmental | |
| Vandal Proof Casing | - |
| Outdoor Ready | - |
| Operating Temperature | -10°C ~ +50°C (+14°F ~ +122°F) *Starting up at above 0°C (32°F) |
| Operating Humidity | 0% ~ 90% |
| Electrical | |
| Power Source | 12VDC, PoE IEEE 802.3at (Class 4) |
| Power Consumption | 12V=, 0.42A, 5.04W PoE, IEEE 802.3at(Class 4), 6.3W |
| Approval | FCC, CE, KC |
| Mechanical | |
| Weight | Main Unit : 0.47kg (1.04 lb) Camera Unit : 0.06kg ( 0.13 lb) |
Name
Description
Size
Downloads
File
DC-V4212XJ_2.4mm_Datasheet.pdf
0.5mb
This is a Full HD ultra-wide-angle indoor network camera with a 132.5-degree horizontal field of view, provided by a fixed 2.4mm F2.0 lens and a 1/2.8-inch CMOS sensor. It supports modern H.265 and H.264 compression at 30 fps and features over 70dB Wide Dynamic Range with Backlight Compensation, High Light Compensation, and Defog for image clarity. Designed for indoor installation, the camera operates from -10°C to +50°C and is powered by 12VDC or PoE 802.3at, consuming up to 6.3 watts. It includes two-way audio, supports edge storage via microSD card, and integrates using the DirectIP 2.0 protocol.
