SECO-LARM - EV-N2806-2W4D - IP 8MP Ultra-Low-Light Active Deterrence Turret Camera
Part number:
EV-N2806-2W4D
Price:

The ENFORCER Ultra-Low-Light Active Deterrence Turret Camera combines 4K-resolution with Active Deterrence. Using a Sony CMOS sensor and ultra-low-light technology, the camera adjusts color information to provide clear images even in dark environments. With Active Deterrence the camera uses AI to distinguish between environmental issues and actual threats and uses red/blue LEDs and sound to warn off intruders, for significantly increased security.


Features:

  • Active Deterrence – uses light and sound to warn intruders they are being monitored, providing an extra level of protection
  • Upload your own custom message to play when an alarm is triggered (WAV or PCM format, up to 256KB)
  • 1/1.8″ 8MP Sony CMOS Sensor
  • Ultra-low-light technology
  • 4K@30FPS, 2160p (3840×2160)
  • 2.8mm, F1.0 Lens
  • Tri-Stream Encoding: H.265, H.264 and MJPEG
  • Corridor mode
  • Operating temperature: -40°~131° F (-40°~55° C)
  • IP67 Weatherproof
  • MicroSD slot (512GB max.)
  • PoE (IEEE 802.3af), 12VDC
  • ONVIF® profiles G, M, S, and T conformant


AI Functions:

  • Face detection
  • Face recognition
  • Human & vehicle detection
  • Perimeter intrusion detection
  • Line crossing detection
  • Stationary object detection
  • Cross counting
  • Heat map
  • Crowd density detection
  • Queue length detection
  • License plate detection
  • License plate recognition
Camera
Image sensor1/2.8″ 8MP Sony CMOS
Effective pixels3840(H)x2160(V)
Scanning systemProgressive scan
Electronic shutter speedAuto, manual; 1/5 s to 1/20,000 s
Minimum illuminationColor: 0.0005Lux at F1.0 (AGC on) 0Lux with IR on
Warmlight viewable lengthDistance up to 82′ (25m)
LEDs2x Warmlight, 1x red, 1x blue
Siren volume78dB
Lens
Lens typeFixed
Focal length2.8mm
Maximum apertureF1.0
Field of viewHorizontal: 110°, Vertical: 59°, Diagonal:132°
Video
CompressionH.265, H.264
Streaming capabilityTriple (3) streams
Resolution2880×1620, 2560×1440, 2304×1296, 1080p (1920×1080), 720p (1280×720)
Bit rate controlCBR/VBR
Bit rateMain stream: 256 to 16384 Kbps Sub stream: 128 to 4096 Kbps Mobile stream: 8 to 1536 Kbps
BacklightDisable (default) BLC, HLC, True WDR
White balanceAuto
Gain controlAuto
Noise reduction3DNR
Smart IRSupport
Image rotation0″, 180″
MirrorDisable, vertical, horizontal, all
Privacy maskingOff, on (4 areas, rectangle)
Region of interestSupport
Active deterrenceSupport
Network
EthernetRJ45
ProtocolTCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP
InteroperabilityONVIF® profiles G, S, and T conformant
Auto registerSupport
Streaming methodMulticast
Max. user access7
Web viewerIE, Chrome, Firefox, Edge
On-board storageBuilt in memory slot Supports up to 512GB MicroSD/SDHC/SDXC
Certifications
CertficationsCE, FCC, RoHS
ONVIF®Profiles G, S, and T conformant
NDAACompliant
Electrical
Power supply12VDC, or PoE (IEEE 802.3af Class 0)
Power consumption< 6W
Environmental
Operating conditions-40°~131° F (-40°~55° C) Less Than 95% RH
Storage conditions-40°~140° F (-40°~60° C)
IP RatingIP67 Weatherproof
Construction
CastingMetal
Dimensionsø4-9/16″x3-15/16″ (ø116×100 mm)
Weight1-lb 5-oz (580g)
