SECO-LARM - RA-4961-MCQ - RF Wireless Magnetic Contact
Part number:
RA-4961-MCQ
Price:
Wireless Magnetic Contact for use with the RA-4961 series receivers
Features:
- For use with the RA-4961 series receivers
- Wirelessly monitor windows, doors, or other areas
- Up to 1,000ft (305m) transmission range*
- Activates each time the door or window is moved
- Magnet can be placed on either side
- Adhesive mount – no screws required
| Frequency | 914.8MHz |
| Channels | 1 |
| Transmission Range | Up to 1,000ft (305m) |
| Power Supply | 2x CR2032 Batteries (Included) |
| Current Draw | Standby- 8μA, Max- 80mA |
| Estimated Battery Life | 132 days (@ 3 triggers/day) |
| Low Battery Indicator | Zone LED on receiver blinks continuously |
| Contact Distance | 3/8” (1cm) |
| Sound Level | 96dB@1ft (30cm) |
| Operating Temperature | -4°~140°F (-20°~60°C) |
| Dimensions | Magnetic Contact- 1-7/8” x 1/4” x 4-3/16” (48 x 7 x 107 mm), Magnet- 3/8” x 1/4” x 1-9/16” (10 x 7 x 39 mm) |
Name
Description
Size
Downloads
File
Datasheet
0.2mb
File
Manual
1.2mb
