Trendnet - TFC-G22SFP - 4-Port Gigabit Switch with SFP Ports

Name: Trendnet - TFC-G22SFP - 4-Port Gigabit Switch with SFP Ports
Brand: Trendnet
SKU: TFC-G22SFP

Part number:

Price:

Dealers only

Add to Quote/Project Registration

Description Specifications Downloads Technical Overview

• 2 x 1Gbps RJ-45 ports
• 2 x 1Gbps SFP ports
• 8Gbps switching capacity
• Sturdy metal switch
• Fanless design
• SFP port accommodates multimode or single-mode modules
• Auto-MDIX RJ-45 ports support full-duplex mode
• NDAA / TAA compliant (U.S. and Canada only)

Standards	• IEEE 802.3 • IEEE 802.3u • IEEE 802.3z • IEEE 802.3ab • IEEE 802.3az
Device Interface	• 2 x Gigabit RJ45 ports (10/100/1000Mbps) • 2 x Gigabit SFP ports (10/100/1000Mbps) • LED indicators
Data Transfer Rate	• Ethernet: 10Mbps (half duplex) 20Mbps (full duplex) • Fast Ethernet: 100Mbps (half duplex) 200Mbps (full duplex) • Gigabit: 2Gbps (full duplex) • 100Mbps SFP: 200Mbps (full duplex) • Gigabit SFP: 2Gbps (full duplex)
Switching Capacity	8Gbps
RAM Buffer	4MB
Jumbo Frames	9KB
MAC Address Table	8K entries
Forwarding Rate	1.488Mpps (64-byte packet size)
Power	• Input: 100 – 240V AC, 50/60 Hz • Output: 5V DC, 1.5A • Max. Consumption: 3.3W
Fan/Acoustics	Fanless design
MTBF	770,000 hours @ 25° C
Operating Temperature	0° – 50° C (32° – 122° F)
Operating Humidity	Max. 90% non-condensing
Dimensions (L x W x H)	101 x 75 x 22.6mm (3.97 x 2.95 x 0.89 in.)
Weight	203.5g (0.45 lbs)
Certifications	CE, FCC, LVD
Warranty	3-year
Package Contents	• TFC-G22SFP • Power adapter (5V DC, 1.5A)

Name

Description

Size

Downloads

File

TFC-G22SFP - 4-Port Gigabit Switch with SFP Ports - Datasheet.pdf

0.3mb

TRENDnet’s compact 4-Port Gigabit Switch with SFP Ports model TFC-G22SFP provides high-bandwidth performance, ease of use and reliability. Boost office network efficiency and eliminate congestion with gigabit speeds and a total switching capacity of 8 Gbps in full-duplex mode. Ideal for networking devices over long distances via fibre connection, this 4-port switch with SFP ports has two SFP ports. Its wall-mountable, fanless design provides installation flexibility.
