The Vi00026 requests maximum IEEE 802.3at PoE power from the PoE source regardless of the PoE load power level.

There are many reasons that IP/PoE CCTV applications may require more power than the end PoE device. This can be due to higher wire resistance, start-up power surge, or features such as day/night and LED startup. Also when using Ethernet extenders the total required PoE power will be higher than the camera power requirement. The Vi00026 eliminates the possibility of power mismatch between the camera PoE power level and the total PoE power requirements for the whole link and avoids camera shutdowns due to insufficient PoE power.

Vigitron’s Vi00026 PoE power class changer takes the guesswork out of all these potential problems. Using a built-in PD and PSE, the Vi00026 helps to bridge the power requirement differences assuring more reliable connections.

Features:

• Requests maximum IEEE 802.3at PoE power from PoE source
• Maintains IEEE 802.3 PoE protection features
• Establishes handshaking from PoE
• Eliminates PoE shut down due to insufficient PoE power level request especially at extended distances
• Assures that reliable PoE is provided to the connected device
