Vigitron’s Vi30126 is the next-generation L2 managed switch designed for High power PoE and high bandwidth network applications. It provides a reliable infrastructure for your business network. The Vi30126 delivers unique intelligent features providing unmatched reliability for critical PoE, bandwidth, and port security. The Vi30126 enables individual port programming to apply PoE individually to each port lowering the potential for power overload resulting in potential damage to the switch and connected devices.

Features:

• High Power PoE Budget: Total 685W power supply with 550W PoE budget providing IEEE 802.3at up to 36W on 24 ports and UPoE up to 72W on 8 ports.
• With programmable PoE up to 36W, with individual port output up to 72W providing power to PTZ domes with heaters and blowers. Additional power is reserved to handle camera surge during start-up and application of auxiliary functions such as day/night, avoiding port PoE shut down.
• Transient Protect determines the difference between the need for additional PoE power and potential damaging shorts by providing extra power when required or shutting down port PoE to protect connected devices
• The 9Gbps switch fabric provides all required bandwidth, even with all ports at their maximum bandwidth to keep video and data quality.
• Automatic connection, re-connection, and port monitoring with PoE application for more reliable start-ups and reducing downtime potentials.
• Programmable multicasting for compatibility and performance with the largest IP video network systems
• Programmable Rapid Spanning Tree for redundant network configuration assuring maintenance of network communication using multiple paths
• Automatic MAC address detection for connected devices for easy connection verification and security programming
• Programmable and auto-detect MAC address binding limiting access for potential hacking
• Layer 2 network switch compliance
• Web filtering and MAC address binding provide two-stage protection against hacking
• SecurPortTM provides complete protection against ghosting when attempts are made to connect unauthorized devices by copying device MAC and IP addresses.
• Provides 24 ports of high power up to 36W PoE at 10/100Mbps
• Provides up to 72W UPoE on 8 ports for powering PTZ domes
• Provides 2 shared fiber/copper Uplink ports @ 1000Mbps to allow for full use of all 24 ports
• Provides over-current, over-voltage, over-temperature, and short protection and auto restart
• SNMP for communicating error messaging to local computers
• Automatic IP and PoE connection and reconnection
• Automatic programmable MAC identification for all connected devices
• Individual port MAC detection and binding for port security
• 685W total power supply with a 550W PoE budget
• Programmable Web Access Filtering (WAF) to prevent unauthorized access
• Transient ProtectTM intelligent PoE sensing to prevent damage from short
• Intelligent Power Limit - automatically determines actual PoE power requirements
• Provides 9G bytes fabric switching rate for handling largest megapixels IP cameras
• SecurPortTM provides individual port and complete switch protection against hacking and ghosting
