GeoVision - 94-NPM01-16A - UVS Mobile VMS Fanless i5
• Powered by Intel i5 13th. Generation Processor
• Windows 11 Pro 64 Bit
• Support GPU Decoding
• 1 Hot Swappable 2.5 in. HDD / SSD bay for up to 2 Terabyte
• Fanless System
• Vibration and Mechanical Shock Protection (5G(RMS) at 5 ~ 500 Hz for SSD)
• Power Ignition Management (ACC)
• Wide Operating Temperature (0°C ~ 70°C / 32°F ~ 158°F for SSD)
• Three Gigabit LAN ports: 2.5 Gigabit x 1, 1 Gigabit x 2
• Compact Flash Slot
• Dual-monitor Display (Choose two from VGA, 2 x DVI-D)
• Optional - Wireless Communication (WiFi / 3G / 4G)
• Optional - GPS Support for Vehicle Tracking
• Built-in GV-NVR
• 3rd Party IP Cameras with H.264 Compatible (License Required)
• Automatic Connection to GV-IP Cameras
• Video analysis
• Dual video streams
• Fisheye camera dewarping function
• Smart device access (iOS and Android)
• E-Mark Certified
• 29 Languages
• Up to 16 channels recommended based on NVR hardware specs
| Processors | Intel 13th Gen i5 |
| IP Inputs | Up to 32 |
| Included IP Licenses | 32 channels of GeoVision IP cameras |
| 3rd Party IP Licenses | Optional |
| Server OS | Windows 11 Pro 64 Bit |
| OS Drive | 512GB SSD |
| Data HDD Included | 0 |
| Max # of HDD | 1 |
| Max HDD Storage | 2TB |
| Removable HDD | Yes |
| Hotswappable HDD | Yes |
| Cfast | 1x CFast socket |
| Serial Port | 1 |
| Audio | 1x mic-in and 1x speaker-out |
| Height (in) | 3.5 |
| Width (in) | 9.5 |
| Depth (in) | 9 |
| Weight Approximate (lbs) | 10 |
| NIC | 3 |
| RAM | 16GB |
| USB Ports | 4 |
| VGA Output | VGAx1, DVI-Dx1, DPx1 |
| Operating Temperature | 0°C to 70°C (32°F to 158 °F) |
| Humidity | 10% to 90% (non condensing) |
| Vibration | Operating, 5 Grms, 5-500 Hz, 3 Axes (with SSD) |
| Shock | Operating, 50 Grms, Half-sine 11 ms Duration (with SSD) |
The GeoVision 94-NPM01-16A UVS Mobile VMS Fanless i5 is a specialised, ruggedised mobile video management system. Designed for installation in vehicles such as buses, police cars, and transit vans, this unit features a fanless design to withstand high-vibration environments and an Intel Core i5 processor to manage high-definition mobile surveillance.
