VA-4800 - Max 48 Supporting CH / 96 AI Resources - IDIS
Part number:
Price:
- • Intrusion Detection
- • Anomaly Detection
- • Crowd
- • Loitering
- • Object Counting & Detection
- • Object Left Behind/Removed
- • Perimeter Monitoring
- • PPE (mask/uniform)
- • Restricted Areas
- • Scene Change
- • Sensor Integration
- • Smoke, Fire, Weapon Detection
| SYSTEM | |
|---|---|
| IDIS Solution Suite | Compatible with IDLA VA Service |
| Network Connection | 1 GbE RJ-45 Ports (1000Base-T) |
| Channels available for Analytics | Up to 48ch |
| GPU | NVIDIA RTX 4000 Ada, 20GB GDDR6 |
| Operating System | Linux Operation System |
| SSD | 1TB(M.2 Type) for OS |
| Processor | Intel i7 14700, 2.1GHz to 5.4GHz |
| Memory | 2x16GB DDR5, 32GB |
| Video Outputs | 1 HDMI |
| USB | 6 ( 2 Front USB 2.0 4 Back ( 3 USB 3.0 TYPE-A 1 TYPE-C)) |
| MECHANICAL | |
| Form Factor | Desktop Tower |
| Unit Dimension (W x H x D) | 173.0mm x 372.90mm x 420.20mm (6.81" x 14.68" x 16.54") |
| Unit Weight | 16.05kg (35.38 lbs) |
| ELECTRICAL | |
| Power Input | 100-240V~, 50/60 Hz, 6.0 - 3.0A |
| Power Supply | Single Power |
| Power Consumption | 270W |
| ENVIRONMENTAL | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Operating Humidity | 0% to 90% |
| ACCESSORIES SUPPLIED | |
| Power Cord | 125V 15A |
| GENERAL | |
| Certifications | FCC, CE |
Name
Description
Size
Downloads
File
VA-4800_Datasheet.pdf
0.4mb
The VA-4800 is a high-capacity dedicated video analytics appliance designed to work with IDIS video management software. It is compatible with the IDIS Deep Learning Analytics service and can process video analytics for up to 48 camera channels, providing up to 96 concurrent AI resources. The system is equipped with an NVIDIA RTX 4000 Ada Generation GPU (20GB), an Intel i7-14700 processor, 32GB of DDR5 RAM, and a 1TB M.2 SSD for the Linux operating system. It features one HDMI output and one Gigabit Ethernet port. The appliance is housed in a desktop tower form factor with a single power supply. It operates within a temperature range of 0°C to 40°C and up to 90% humidity, with a power consumption of 270W from a 100-240V AC source.
