Digital Watchdog - DW-ENC4K16 - 4K Encoder, Supports UHDoC HD-Analog, HD-CVI,DH-TVI and CVBS, 16ch, Streaming 4K at 8fps, 5MP at 12fps, 4MP at 15fps and up to 2.1MP/1080P at 30fps, Simultaneous H.265-H.264 Streaming, 8 Audio In,1Audio Out, Two Way Au
Part number:
DW-ENC4K16
Price:
The NDAA-compliant Compressor™ UHDoC to IP signal encoder converts up to 16 HD-Analog, HD-TVI, HD-CVI and CVBS signals into IP video streams at up to 4K resolution. Fully integrated with DW Spectrum® IPVMS, the DW-ENC4K16 is an ideal addition for applications looking to upgrade their existing analog infrastructure, maximizing their ROI, to the unmatched performance and ease of use of IP video management without a complete system replacement.
Features:
- The most cost-effective path to IP
- Universal HD over Coax® HD-Analog, HD-TVI, HD-CVI and CVBS signal support
- Connect your analog cameras to DW Spectrum® IPVMS or any ONVIF approved VMS
- Convert up to 16 analog signals to 4K IP video streams
- Local video output for local display
- Streaming 4K at 8fps, 5MP at 12fps, 4MP at 15fps and up to 2.1MP/1080P at 30fps
- Simultaneous H.265, H.264 streaming
- Works with DW Spectrum® IPVMS recording license (requires DW-SPCP16LSC016 or DW-SPCP04LSC004)
- Motion detection support
- 8 audio inputs, 1 audio output
- Two-way audio through DW Spectrum IPVMS
- OSD and PTZ control via coax (UTC)
- 1x RS-485 Interface for PTZ control
- Search and playback from DW Spectrum® IPVMS
- Frame rate and bandwidth control
- 16 alarm inputs, 4 alarm outputs
- Event notifications via email with image
- ONVIF conformant, Profile S
- NDAA compliant
| Specifications | |
| VIDEO | |
| Display screen split | 1, 16, 4, 8 |
| Display Speed | 4K at 15fps, 4MP, 2.1MP/1080p, 720p, 960H, D1 at 30fps, 5MP at 20fps |
| Stream resolution output | BNC: CVBS, 960H, True HD: 3840 × 2160, 1920 × 1080, 1280 × 1024, VGA: 1920 × 1080, 1280 × 1024 |
| Video input | 16CH BNC input, BNC interface (1.0Vp-p; 75Ω), HD over Coax® technology with HD-Analog, HD-TVI and CVBS analog signal up to 4K |
| Video output ports | BNC, True HD, VGA |
| PERFORMANCE | |
| Advanced functions | Firmware upgrade by UBS, Log file system, System settings via web browser, Digital zoom, Import and export settings, Motion detection , Privacy masks |
| Alarm in/out | 16 alarm inputs, 4 alarm outputs, Terminal block |
| Alarm management | Alarm input, Locally and via DW Spectrum® IPVMS, Motion detection, Sensor activation, System reboot, User login, Video loss |
| Audio in/out | 1 RCA output, 8 RCA inputs, linear, 600Ω |
| Performance Audio codec | G.711(U/A) |
| Performance Notifications | PTZ preset activation, Snapshot, Alarm output activation, Buzzer alarm, FTP, Local popup display, Notifications via email, Push text notifications |
| Performance Remote software | DW Spectrum® IPVMS |
| Performance Web viewer | Google Chrome® browser, Internet Explorer® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS |
| Serial | 1x RS485 port for PTZ support, 1x USB 2.0, 1x USB 3.0, PTZ control via Coax (UTC) |
| NETWORK | |
| Bitrate mode | CBR, VBR |
| LAN | 10/100/1000 Base-Tx Ethernet (RJ045) |
| Max bitrate | 32Kbps - 5Mbps |
| Network Compression | H.264, H.265 |
| Protocol | DDNS, DHCP, DNS, FTP, HTTP, NTP, ONVIF, PPPoE, RTSP, SMTP, SNMP, Static, TCP/IP, UPnP |
| Security | Digest authemtication (ID/PW), HTTPS, Multi-user authority |
| Streaming | Dual-streaming |
| Supported protocols | ONVIF |
| Transmission speed live | 4MP: 15fps, 4K at 8fps, 5MP at 12fps, Up to 2.1MP/1080p: 30fps |
| Max throughput | 96Mbps |
| ELECTRICAL | |
| Power Consumption | Max 30W, 2.5A |
| Power Requirements | 12V DC, 4A |
| GENERAL | |
| Accessories (Optional) | DW-G419RE (included with DW-ENC4K16) |
| Licenses (Optional) | DW-SPCP04LSC004 - Four (4) DW Spectrum® Analog Encoder IPVMS Licenses, DW-SPCP16LSC016 - Sixteen (16) DW Spectrum® Analog Encoder IPVMS Licenses |
| Operating humidity | 10-90% (non-condensing) |
| Operating temperature | 4°F - 122°F (-10°C ~ 50°C) |
| Recorder Dimensions (H X W X D) | 14.96” x 10.55” x 1.77” (380 × 268 × 45mm) |
| Warranty | 2 Year Warranty |
