Acti - CAM-6520 - 0.35MP, Indoor Speed Dome, Day / Night, 23x optical
Part number:
CAM-6520
Price:
Pan-Tilt-Zoom cameras for indoor and outdoor applications. Speed Domes with endless panning. High zoom ratio. Extreme WDR and Low Light.
Features:
- 0.35 Megapixel
- Day & Night
- Endless Pan & Tilt
Device
| Product Type | Speed Dome |
| Maximum Resolution | 0.35MP |
| Application Environment | Indoor |
| Day / Night | Yes |
| Low Light Sensitivity | Standard |
| Minimum Illumination | Color: 0.1 lux at F1.6 (30 IRE , 2400 K); B/W: 0.01 lux at F1.6 (30 IRE, 2400 K) |
| Mechanical IR Cut Filter | Yes |
| IR LED | No |
Lens
| Focal Length | Zoom, f3.6-82.8mm |
| Aperture | F1.6-F3.7 |
| Zoom Ratio | 23x optical, 12x digital |
PTZ
| Panning Range | 360° endless |
| Tilting Range | -10°~190° |
Video
| Compression | MPEG-4 ASP |
| Maximum Frame Rate vs. Resolution | 30 fps at 720 x 480 25 fps at 720 x 576 |
| Multi-Streaming | Single stream based on a single configuration |
| Bit Rate | 28Kbps - 3Mbps (per stream) |
| Bit Rate Mode | Constant |
| Server-based Analytics | Object Line Counting, ピープルカウント, Face Detection, Object Based Motion Detection, Tamper, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Smoke Detection, Heat Map, Dwell Time, People Queue Detection, (Require PC-based or standalone IVS or ALPR Server. Contact ACTi support for recommendations on how to maximize analytical accuracy) |
Audio
| Audio Type | 2-way, Line-in, Line-out |
Network
| Network Protocol & Service | IP, TCP, UDP, DHCP, PPPoE, HTTP, DNS, DDNS, NTP, RTP, RTSP, IGMP, ICMP, ARP, ToS |
| Security | Password protected user level |
Integration
| Unified Solution | Fully compatible with ACTi software |
General
| Power Source | AC 24V |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
