AVYCON - AVC-NUE81F28 - 8MP H.265 Turret Network Camera
AVYCON - AVC-NUE81F28 - 8MP H.265 Turret Network Camera
Part number:
AVC-NUE81F28
Price:
Dealers only
Add to Quote/Project Registration
Description Specifications Downloads

8MP (4K), H.265+ InfiniteColor, Turret AI Diversity Active Deterrence IP Camera, F1.0, True WDR, Ultra Low Light, 8MP@30FPS, Full Color (white light), Built-in Mic, Speaker (2-way), Siren, 2.8mm Fixed Lens, MicroSD, Onvif, DC12V / PoE, IP67, White.



Features:

  • 8MP (3840x2160) H.265+, H.265, H.264+, H.264, MJPEG
  • Max. resolution: 3840x2160
  • Full Color / Active Deterrence Camera
  • 2.8mm Fixed Lens (F1.0)
  • 3D DNR, WDR, HLC, BLC, ROI encoding
  • Intelligent Analytics
  • White Light LED / Strobe (Blue & Red) Light
  • Built-in MIC / Speaker
  • Built-in micro SD card slot with video and still image capture function (up to 256GB)
  • IP67 ingress protection
  • DC12V/PoE power supply
  • Support remote monitoring by AVYCON ONE (Mobile APP) and AVYCON CMSONE (CMS)
Camera
Imaging Device1/1.8" Progressive CMOS
ResolutionMain Stream : 3840x2160, 3072x1728, 2592x1944, 2592x1520, 2304x1296, 1920x1080
Sub Stream :  1920x1080, 1280x720, 640 x 480
Mobile Stream: 640x480, 320x240
Max. FramerateMain Stream: Max. 30fps/25fps(60Hz/50Hz)
Sub Stream: Max. 30fps/25fps (60Hz/50Hz)
Mobile Stream : Max. 30fps/25fps (60Hz/50Hz)
Min. IlluminationColor : 0.0005lux @ F1.0(AGC on)
Video OutN/A
Lens
Focal Length (Zoom Ratio)2.8mm Fixed
Max. Aperture RatioF1.0
Angular Field of ViewHorizontal: 110°, Vertical: 59°, Diagonal: 132°
Min. Object Distance3.28ft (1M)
Focus ControlN/A
Lens TypeFixed(M16)
Pan / Tilt / Rotate
Pan / Tilt / Rotate RangeN/A
Operational
Camera TitleTitle displayed up to 32 characters
Day & NightFull Color Mode
Backlight CompensBLC, HLC, WDR
Digital Noise Reduction3D DNR
Digital Image StabilizationN/A
Motion DetectionRectangle Grid (8 Levels of Sensitivity)
Privacy Masking4 Rectangle Zones
Gain ControlAUTO
White BalanceAUTO / MANUAL
LDCN/A
Eletronic Shutter SpeedAUTO / Manual (1/5 ~ 1/20000s)
Video RotationFlip / Mirror
AnalyticsFace Detection(FD) Pedestrian&Vehicle Detection(PD&VD) Intrusion Detection(ID)
Line Crossing Detection(TD) Tripwire Counting(TC) Stationary Object Detection(OBJ)
Heat Map(HM) Crowd Density Detection(CD) Queue Length Detection(QD)
license Plate Detection(LPR) Rare Sound Detection(RSD)
Alarm I/ON/A
Alarm TriggersMotion, Sound Detection
Alarm EventsWarning Light, Siren, Notofication vis E-mail, Image file upload vis FTP, Video file upload via FTP,
Image file upload to Cloud (Drobox), Video file upload to Cloud (Dropbox),
Micro SD recording at event triggered, Event Push via HTTP / UDP,
Audio InBuilt-in MIC
Audio OutBuilt-in Speaker
IR Viewable LengthNo IR / White LED Max. 91ft (25M)
Network
EthemetRJ45(10/100BASE-T)
Video CompressionH.265+/H.265 Main Profile, H.264+/H.264 High Profile,MJPEG(Sub Stream Only)
Audio CompressionG.711a / G.711u
Bitrate ControlCBR or VBR (256Kbps ~ 16Mbps)
StreamingUnicast/Multicast
ProtocolTCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
SecurityLogin Authentication, IP Address Filtering , User access log
Application Programming InterfaceONVIF Profile S/G/T, REST API
General
Webpage LanguageEnglish, Korean
Edge StorageMicro SD/SDHC/SDXC Slot (up to 256GB) with video and still image capture function
MemoryN/A
Environmental & Electrical
Operating Temperature / Humidity-22 ~ 131 F (-30～+55°C) / less than ≤ 95% RH
Storage Temperature / Humidity-22 ~ 140 F (-30～+60°C) / less than ≤ 95% RH
CertificationIP67
Input VoltagePoE(IEEE802.3at) /12VDC
Power ConsumptionTBD
Mechanical
Color / MaterialWhite / Metal
Product Dimensions / WeightTBD
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF)
Observe (63PPM/ 19PPF)
Recognize (125PPM/ 38PPF)
Identify (250PPM/ 76PPF)
Name
Description
Size
Downloads
File
Datasheet
0.1mb
File
Quick Start Guide
1.9mb
