Dahua - A83ALBZ - 4K IR Vari-focal HDCVI Dome Camera
This product has been discontinued.
Part number:
A83ALBZ
Price:

HDCVI technology seamlessly integrates traditional analog surveillance systems with upgraded, high-quality HD video, making it the best choice to protect security investments. The plug and play approach enables full HD video surveillance without the hassles of configuring a network.



Experience the superior clarity of Dahua’s Ultra 4K HDCVI cameras for vast coverage and superior image details. As the world’s first 4K over coax cameras, the Dahua Ultra 4K HDCVI series leverages existing coax infrastructures to deliver forensic-level images seamlessly and more cost effectively. The outstanding performance, easy installation and rugged design make the camera an ideal choice for mid- to large-size businesses and for applications in large, open spaces (city centers, parks, campuses) where highly reliable surveillance and construction flexibility are valued.



Thanks to the camera’s true day/night IR cut filter and Smart IR images are crisp and clear in both day or nighttime applications. The camera’s IP67 rating, IK10 vandal resistance, and low temperature rating with integrated heater makes this camera ideal for challenging environments.



Features:

  • 1/1.8-in. 8MP Progressive-scan CMOS Imager
  • 4K (3840 x 2160) at 15 fps
  • 3.7 mm to 11 mm Motorized Optical Zoom Lens
  • True Wide Dynamic Range (120 dB) and 2D and 3D Noise Reduction
  • HD and SD Dual-output
  • Maximum IR length 50 m (164 ft), Smart IR
  • IP67 Ingress Protection and IK10 Vandal Resistance
  • 24 VAC or 12 VDC Power Supply
  • 12 VDC Output
  • Designed for Extreme Temperature Environment
Technical Specification
Camera
Image Sensor1/2-in. CMOS Imager
Effective Pixels3840(H) x 2160(V), 8 MP
Scanning SystemProgressive
Electronic Shutter Speed1/1 s to 1/100,000 s
Minimum IlluminationColor: 0.01 lux at F1.5, 30 IRE
0 lux with IR on

S/N RatioMore than 65 dB
IR DistanceUp to 50 m (164.04 ft)
IR On/Off ControlAuto, Manual
IR LEDsThree (3)
Lens
Lens TypeMotorized Lens / Fixed Iris
Mount TypeBoard-in
Focal Length3.7 mm to 11 mm
Maximum ApertureF1.5
Angle of ViewHorizontal: 46° to 112°
Focus ControlAuto, Manual
Close Focus Distance
200 mm (7.87 in.)
Pan / Tilt / Rota on

RangePan: 0° to 355°
Tilt: 0° to 65°
 Rotation: 0° to 355°
DORI Distances¹
 Detect
 (8 ppf)
Wide-angle83 m
(273 ft)

Telephoto190 m
(624 ft)

Video
Resolution8 MP (3840 x 2160)
Frame Rate3840 x 2160 at 15 fps
1280 × 720 at 30 fps

Video OutputOne (1) BNC HDCVI 4K Ultra High-definition Channel
and, One (1) BNC CVBS Channel

Video Transmission²RG-6/U Coax
Day/NightAuto (ICR), Manual
On-Screen DisplayMulti-language
BLC ModeBLC, HLC, WDR
WDR120 dB
Gain ControlAGC
Noise Reduction2D/3D
White BalanceAuto, Manual
Smart IRAuto, Manual
Interface
AudioInput: One (1) Channel
AlarmInput: Two (2) Channels
Output: One (1) Channel

Electrical
Power Supply, Input24 VAC ±25% or 12 VDC ±25%
Power, Output12 VDC, 4 W maximum
Power Consumption12.4 W maximum
Cer fica ons
SafetyUL60950-1
CAN/CSA C22.2 No.60950-1

Electromagnetic CompatibilityFCC CFR 47 FCC Part 15 subpart B,
(EMC)ANSI C63.4-2014
Environmental
Operating Conditions-40 °C to +60 °C (-40 °F to +140 °F), with built-in heater
Less than 95% RH
 * Initiate Startup above -40 °C (-40 °F)
Storage Conditions-40 °C to +60 °C (-40 °F to +140 °F),
Less than 95% RH

Ingress ProtectionIP67
Vandal ResistanceIK10
Construc on
CasingAluminium
Dimensionsø159.10 mm x 117.90 mm (ø6.26 in. x 4.64 in.)
Net Weight0.90 kg (1.98 lb)
Gross Weight1.20 kg (2.65 lb)
