Dahua - DH-PFS4226-24GT-360 - 24-port Gigabit PoE Switch
Part number:
DH-PFS4226-24GT-360
Price:
The DH-PFS4226-24GT-360 is a dedicated PoE switch designed especially for the security industry.The switch provides 24 Gigabit Ethernet PoE ports and supports Layer 2 network management and PoE management with high-speed data forwarding. The switch offers two Hi-PoE ports that deliver up to 60 W of power per port, and delivers up to 360 W of total power to PoE devices.
Features:
- Layer 2 Managed PoE Switch
- Supports the IEEE802.3af and IEEE802.3at Standards and Hi-PoE
- STP/RTSP/MSTP Network Redundancy
- SNP Network Management
- Web, Telnet, and CLI Command Configuration
- QoS (IEEE802.1p/1Q), CoS/ToS to Increase Determinism
- Enhanced Network Security with IEEE802.1X, SNMP v1/v2c/v3, HTTPS, and SSH/SSL
- 4M Data Cache, Real-time Transmission
- MAC Auto Study and Aging, 8K MAC Address List Capacity
| Ethernet Ports | Two (2) 1000 Base-X 24 x 10/100/1000 Base-T Ports (PoE Power Supply) |
| RS232 Serial Console | One (1) RS232 Built-in to RJ-45 Connector for CLI Management: • Baud Rate: 115,200 bps • Data Bits: 8 • Odd-even Check: None • Stop Bit: 1 |
| PoE Features | • Hi-PoE: Ports 1 and 2 Consumption: up to 60 W per port • IEEE802.3af, IEEE802.3at: Ports 3 to 24 Consumption: up to 30 W per port • Total PoE Budget: ≤ 360 W |
| PoE Protocol | PoE (IEEE802.3af), PoE+ (IEEE802.3at), Hi-PoE |
| Switching Capacity | 52 Gbps |
| Packet Forwarding Rate | 38.688 Mpps |
| Packet Buffer Memory | 4 MB |
| Power Requirements | 100 VAC to 240 VAC, 50/60 Hz |
| Working Temperature | –10° C to 55° C (14° F to 131° F) |
| Application Humidity | 5% to 95% |
| Lightning Protection | Common Mode: 2 KV Differential Mode: 1 KV |
| Dimensions (W x D x H) | 440.0 mm x 300.0 mm x 44.0 mm (17.32 in. x 11.81 in. x 1.73 in.) |
| Weight | 3.52 kg (7.76 lb) |
Name
Description
Size
Downloads
File
Data Sheet
0.4mb
File
User Manual
0.7mb
File
A&E Document
0mb
