DSS Pro is a comprehensive and expandable Dahua VMS for flexible, scalable, reliable and powerful central management. With client-server architecture, DSS Pro provides central management, information sharing, convenient connections, and multi-service cooperation. The software provides basic functions such as user permission management, device management, alarm management, and central storage, but also delivers advanced features of video wall and map configuration, access control features, video intercom, attendance, and analytic functions such as face detection and object detection. It also integrates add-ons such as business intelligence and traffic surveillance.
One radar device license for DSSPro V8 (this radar channel license is for radar tracking function of PTZ)
Compatibility
DSS Pro is compatible with all Dahua IP-enabled devices: network cameras, NVRs, DVRs, video intercom devices, and access control devices.
Fisheye Camera Support
The software features full support for Dahua Fisheye cameras. The software supports options for the Fisheye camera installation and offers dewarp modes. Dewarping solves the problem of distortion in the circular panoramic view in both live or playback modes.
Scalability and Interoperability
DSS Professional can be used in various applications such as parks, chain stores, and logistics and scale to future needs. The software supports up to 2,000 channels, 1,000 doors and 400 TB storage capacity per server but can expand up to 20,000 channels and 4 PB storage capacity through a more distributed architecture.
Access Control and Video Intercom
DSS Pro offers full support and integration for access control and video intercom products to support a complete security system. The server monitors door status and events, manages access rights, and support advanced rules management. In addition to access controls, the server supports two-way communication between intercom and control center.
Video Wall
The software offers settings to configure all aspects of a video wall application including layout, live preview, scheme configuration, and tour setup. In addition, the application supports video wall splicing and roaming.
Management Operations and Applications
DSS Pro manages the devices and users accounts for an entire organization. Operators can assign different camera ranges, active use periods, and business roles for each user. The server also supports different schemes for various events, including IVS, to record and view all event history information.
Features:
- Integrates All Management Functions into One Client
- Allows Device Initialization and Management
- Live Video Playback from Edge Device
- Supports Access Control and Video Intercom Integration
- Configure Video Wall Layout and Scheme
- Offers Fisheye Camera Dewarping on Live View
- DSS Pro V8 Video Base License: Includes 16 video channels (IPC, NVR, FR, LPR), Required to purchase additional video channel licenses.
| Technical Specification | |||
| Hardware – Server | |||
| Operating System | Windows Server 2019 Standard (64-bit) Windows 10 20H2 Pro (64-bit) Windows 11 21H2 Pro (64-bit) | ||
| CPU | Recommended | Intel® Xeon® Silver 4114 @ 2.2 GHz 10 Core Processor | |
| Minimum | Intel® Xeon® E-2224 3.4GHz, 8M cache | ||
| Memory | Recommended | 16 GB | |
| Minimum | 8 GB | ||
| System Disk | 7200 RPM Enterprise Class HDD 1 TB, 500 GB free space for DSS | ||
| Storage Disk | 7200 RPM Enterprise Class HDD 1 TB, 500 GB free space for DSS | ||
| Network Connection | Recommended | Four (4) 1000 Mbps Ethernet Port | |
| Minimum | Two (2) 1000 Mbps Ethernet Port | ||
| Languages | English (United States), Simplified Chinese | ||
| Record and Event Plan (Cont.) | Event Rules | 3,000 | |
| Combined Event Rules | 100 | ||
| Combined Events | 1,000 | ||
| Map | Person and Vehicle Groups | 999 | |
| Sub Groups per Level | 10 | ||
| Hierarchies | 8 | ||
| Offline GIS Map Package | 500 MB | ||
| Raster Maps | Up to 256 | ||
| Submaps per Map | Up to 32 | ||
| Raster Map Size | 15 MB | ||
| Raster Map Resolution | 8,100 x 8,100 | ||
| Resources per GIS Map | Up to 300 | ||
| Resources per Raster Map | Up to 300 | ||
| Person and Vehicle Management | Persons | 3,00,000 | |
| Cards | 6,00,000 | ||
| Faces | 3,00,000 | ||
| Finger Prints | 6,00,000 | ||
| Vehicles | 50,000 | ||
| Vehicle Watch List | 32 | ||
| Vehicles per Watch List | 50,000 | ||
| Intelligent Analysis | People Counting Groups | 30 | |
| People Counting Rules per Group | 20 | ||
| Access Control | Persons for Door Access Rules | 30,000 (1 password, 2 face images, 3 fingerprints, and 5 cards for each person) | |
| Zones | 256 | ||
| Door Access Rules | 500 | ||
| Public Passwords | 1,500 | ||
| Elevator Access Rules | 300 | ||
| Persons for Elevator Access Rules | 20,000 | ||
| Visitor | Visitors (Registrations and Appointments) | 10,000 | |
| Video Intercom | Rooms | 5,000 | |
| Persons per Room | 10 | ||
| VDP Accounts | 5 | ||
| Entrance/Exit Management | Vehicle Groups | 32 | |
| Number of Entrances and Exits | 60 | ||
| Parking Lots | 16 | ||
| Entrance/Exit Points | 60 | ||
| Total Entrances | 30 | ||
| Total Exits | 60 | ||
| License Plates per Reserved Parking Space | 10,000 | ||
| Parking Space Detectors per Parking Lot | 500 | ||
| Parking Space per Parking Lot | 1,500 | ||
| Parking Available Displays per Parking Lot | 30 | ||
| Image Size per Layer | 15 MB | ||
| Resolution per Layer | 8,100 x 8,100 | ||
| Total Layers | 128 | ||
| Layers per Parking Lot | 16 | ||
| Resources per Layer | 600 | ||
| Parking Spaces per Layer | 1,000 | ||
| Hardware – Control Client | |||
| Operating System | Windows Server 2019 Standard (64-bit) Windows 10 20H2 Pro (32-bit) Windows 10 20H2 Pro (64-bit) Windows 11 21H2 Pro (64-bit) | ||
| CPU | Recommended | Intel® Core i7-11700 at 2.50 GHz | |
| Minimum | Intel® Core i5-9500 at 3.00 GHz | ||
| Memory | Recommended | 16 GB | |
| Minimum | 16 GB | ||
| Graphics Card | Recommended | NVIDIA® GeForce® RTX 3060 | |
| Minimum | Intel® UHD Graphics 630 | ||
| Storage | Recommended | 200 GB free space | |
| Minimum | 100 GB free space | ||
| Network Connection | One (1) 1000 Mbps Ethernet Port | ||
| Languages | Arabic, Bulgarian, Czech, Danish, English (United states), Finnish, French, German, Hebrew, Hungarian, Italian, Japanese, Korean, Macedonian, Polish, Brazilian Portuguese, Russian, Simplified Chinese, Spanish, Thai, Traditional Chinese, Turkish, Ukrainian, Vietnamese | ||
| Hardware – DSS Mobile Client | |||
| iPhone | Model: iPhone 5S or later OS: iOS 10.0 or later | ||
| Android | Resolution: 1280 x 720 or higher RAM: 2 GB or more OS: Android 5.0 or later | ||
| Language | Arabic, English (United States), French, Russian, Simplified Chinese | ||
| Total System Management Functions | |||
| Organization, User, Roles | Organization | 10 Hierarchies; 999 Organization Total | |
| Roles | 500 User Permissions | ||
| Roles per user | 32 | ||
| Users | 200 Online Users 2,500 Total Users | ||
| Users for VDP Mobile App | 500 Online Users 5,000 Total Users | ||
| Record and Event Plan | General Recording Plans | 3,000 | |
| Motion Detection Recording Plans | 3,000 | ||
| Video Retrieval Plans | 3,000 | ||
| File Retrieval Plans | 3,000 | ||
| Data Records | Alarms | 20,00,000 | |
| Number Plates | 20,00,000 | ||
| ANPR | 20,00,000 | ||
| Metadata | 20,00,000 | ||
| Access Control | 20,00,000 | ||
| Video Intercom | 20,00,000 | ||
| Visitors | 20,00,000 | ||
| Entrances | 20,00,000 | ||
| Exits | 20,00,000 | ||
| Forced Exits | 20,00,000 | ||
| Historical Count | 20,00,000 | ||
| In-Area Statistical | 20,00,000 | ||
| Heat Map | 20,00,000 | ||
| Operator Logs | 20,00,000 | ||
| Service Logs | 20,00,000 | ||
| Attendance | Attendance Terminals | 64 | |
| Attendance Periods | 64 | ||
| Attendance Shifts | 100 | ||
| Synthesis | Bridges | 5 | |
| Incoming Trigger Events | 100 | ||
| Incoming Trigger Sources | 500 | ||
| Inspection | Intelligent Inspection | 1,000 | |
| Inspection Organizations | 10 | ||
| Levels of Inspection Organizations | 10,000 | ||
| Inspection Objects | 10,000 | ||
| Inspection Points | 10,000 | ||
| Inspection Points per Organization | 1,000 | ||
| Inspection Plans | 1,000 | ||
| Inspection Pointers per Inspection Plan | 100 | ||
| Notification Center Messages | 1,000 | ||
