Dahua’s Lite Series network video recorders offer excellent performance and high recording quality for network video security applications. For applications where details are critical for identification, this professional NVR provides a powerful processor with up to 4K resolution. Additionally, the NVR features a mouse shortcut operation menu, remote management and control, center storage, edge storage, and back up storage.
Designed as a cost-effective and easy to install recorder, this NVR is an ideal addition to any security system.
The NVR is compatible with numerous third-party devices making it the perfect solution for security systems with or without a video management system (VMS). Its open architecture supports multi-user access and it is compatible with ONVIF S, T, and G protocols, enabling interoperability when combined with 4K cameras.
Features:
- Smart H.265+ and Smart H.264+ Dual Codec
- Maximum 80 Mbps Incoming Bandwidth
- Up to 8 MP Resolution for Preview and Playback
- Simultaneous HDMI and VGA Video Output
- Supports Remote Configuration and Management of Network Cameras
- Supports P2P Remote Security and DMSS Mobile App
- Records Analytics+ Data from Edge Cameras
- Four (4) PoE/PoE+ Ports
- Five-year Warranty (for products sold through an authorized Dahua Dealer)
Audio and Video
| IP Camera Input | Four (4) Channels |
| Audio | Input: One (1) Channel, RCA Output: One (1) Channel, RCA |
Analytics+ Recording
Perimeter Protection | Channels | Four (4) |
| Search | By channel, time, event type | |
| SMD+ | Channels | Four (4) |
| Search | By target classification (human or vehicle) |
Display
| Interface | One (1) HDMI One (1) VGA |
| Native Output Resolution | 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720 |
| Maximum Decoding | Two (2) Channel of 8 MP at 30 fps Four (4) Channels of 4 MP at 30 fps |
| Multi-screen Display | 1/4 |
| On-screen Display | Camera Title, Time, Video Loss, Camera Lock, Motion Detection, Recording |
Recording
| Video Compression | Smart H.265+, H.265, Smart H.264+, H.264, MJPEG |
| Audio Compression | PCM, G.711A, G.711Mu, G.726 |
| Supported IP Camera Resolution | 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 720p, D[1] |
| Maximum Recording Bandwidth | 80 Mbps |
| Record Mode | Manual Recording; Alarm Recording; SMD Recording; Smart Recording |
Video Detection and Alarm
| General Alarms | Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm |
| Anomaly Alarms | Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception |
| Analytics+ Alarms | Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms |
| Alarm Actions | Recording, snapshot, audio, buzzer, log, preset, and email |
Network
| Ethernet | One (1) RJ-45 Port (10/100 Mbps), Self-adaptive |
| PoE | Four (4) Ports (IEEE802.3af/at) |
| Network Function | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS); P2P; Auto register |
| Maximum User Access | 128 |
| Mobile Operating System | IOS, Android |
| Browser | Chrome, IE 9 or later |
| Interoperability | ONVIF Profiles S,T,G; CGI, SDK |
Storage
| Internal HDD | One (1) SATA III Port, Up to 10 TB capacity per HDD |
| HDD Mode | Single |
Auxiliary Interface
| USB | Two (2) USB 2.0 Ports (rear panel) |
Electrical
| Power Supply | 48 VDC, 1.25 A |
| NVR Power Consumption | < 10 W, without HDD |
| Total PoE Budget | 25.5 W single port, 36 W total |
Environmental
| Operating Conditions | –10° C to +50° C (+14° F to +122° F), 10% to 93% RH |
| Storage Conditions | 0° C to +40° C (32° F to 104° F), 30% to 85% RH |
Construction
| Dimensions (W x L x H) | 204.60 mm x 206.40 mm x 45.60 mm (8.06 in. x 8.12 in. x 1.80 in.) |
| Net Weight | 0.50 kg (1.10 lb), without HDD |
| Gross Weight | 1.43 kg (3.15 lb), without HDD |
