The Dahua 5 MP Starlight camera offers Smart Motion Detection for improved alarm accuracy from intrusion and tripwire functions. The camera is ideal for a host of diverse applications — Starlight+, True Wide Dynamic Range, and IR illumination allow the camera to operate in any lighting condition. The camera is a component of the Dahua ArcticPro series and is rated to IP67 allowing the camera to deliver high-quality and reliable video in the harshest environments.
Features:
- 1/2.7 in. 5 MP Progressive-scan CMOS Sensor
- Triple-stream Encoding
- Smart H.265+ and Smart H.264+ Dual Codec
- 5 MP (2592 x 1944) at 20 fps, 2.8 mm Fixed Lens
- Starlight Technology for Low-light Applications
- Analytics+ Function – Perimeter Protection
- Smart Motion Detection for Improved Alarm Accuracy
- True Wide Dynamic Range (120 dB) and Day/Night IR Cut Filter
- Maximum IR LED Distance 50 m (164.04 ft)
- Built-in Microphone
- ArcticPro Series Camera – Operational down to –40° C (–40° F)
- IP67 Ingress Protection
- Five-year Warranty (for products sold through an authorized Dahua Dealer)
Camera
| Image Sensor | 1/2.7-in. 5 MP CMOS |
| Effective Pixels | 2592(H) x 1944(V) |
| RAM/ROM | 512 MB/128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto, Manual, 1/3 s to 1/100,000 |
| Minimum Illumination | Color: 0.005 lux at F1.6 0 lux at F1.6 (IR on) |
| IR Distance | Up to 50.0 m (164.04 ft) |
| IR On/Off Contro | Auto, Manual |
| IR LEDs | Three (3) |
Lens
| Lens Type | Fixed Focal |
| Iris Type | Fixed Aperture |
| Mount Type | M12 |
| Focal Length | 2.8 mm |
| Maximum Aperture | F1.6 |
| Angle of View | Horizontal: 98° Vertical: 72° Diagonal: 130° |
| Close Focus Distance | 0.90 m (2.95 ft) |
Name
Description
Size
Downloads
File
installation Guide
0.9mb
File
Datasheet
0.6mb
File
AE Specifications
0mb
accessories
