Dahua - N54B3P20 - 4K 16CH 1.5U ePoE NVR 20T
Part number:
N54B3P20
Price:

Dahua’s Pro Series network video recorders offer excellent performance and high recording quality for IP video surveillance applications. For applications where details are critical for identification, this professional NVR provides a powerful processor with up to 4K resolution. Additionally,
the NVR features a mouse shortcut operation menu, remote management and control, central storage, edge storage, and back up storage options.

Dahua’s innovative ePoE technology offers a plug-and-play solution to transmit power and data over long distances via Ethernet or coaxial cables, reducing installation time and saving money. ePoE technology is a viable, cost-effective solution for extending transmission distances and for converting existing, coax-based analog systems into IP systems. For video security and surveillance installers, ePoE technology saves time and money by reducing overall cabling requirements, allowing for existing coax cable to be used, and minimizing the number of peripheral devices needed. For new installations, ePoE offers the ability to design long-distance applications without the need for additional repeaters.



Features:

  • Smart H.265+ and H.264 Dual Codecs
  • Maximum 320 Mbps Incoming Bandwidth
  • Up to 12 MP Resolution for Preview and Playback
  • Ports 1 to 8 Support ePoE and EoC Signal Transmission, up to 800 m (2524 ft)
  • HDMI and VGA Simultaneous Video Output
  • Intelligent Video System
  • Compatible with Dahua Smart Motion Detection+ Cameras
  • Five-year Warranty (for products sold through an authorized Dahua Dealer)

System

Main ProcessorQuad-core Embedded Processor
Operating SystemEmbedded LINUX

Audio and Video

IP Camera Input16 Channels
AudioInput: One (1) Channel, RCA
Output: Two (2) Channels, RCA

Display

InterfaceTwo (2) HDMI Ports
Two (2) VGA Ports
Native Output ResolutionHDMI 1: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720, 1024 × 768
HDMI 2: 1920 x 1080
VGA 1: 1920 × 1080, 1280 × 1024, 1280 × 720, 1024 × 768
VGA 2: 1920 × 1080
Maximum DecodingFour (4) Channels of 8 MP at 30 fps 16 Channels of 1080p at 30 fps
Multi-screen DisplayFirst Screen: 1/4/8/9/16
Second Screen: 1/4/8/9/16
On-screen DisplayCamera Title, Time, Camera Lock, Motion Detection, Recording
