1/2.8-in. 8MP CMOS, WDR (120dB), H.265/H.264, 30fps@8MP, 2.7-13.5mm/F1.0 Motorized, LED Distance 131ft, IR Distance 164ft, 1/1 Audio In/Out, 1/1 Alarm In/Out, Micro SD, Max. 256GB, Built-in Mic, IP67, DC12V, PoE, Smart Dual-illuminators, Two-way talk w/ Dual Microphone, AI Coding, Perimeter Protection, Smart Motion Detection+, Red/Blue Lights and Siren
The Dahua Three-in-One Camera (TiOC) offers multiple features working in tandem to assist with deterrence and low-light detection while delivering high-resolution video images. The camera also features Perimeter Protection and Smart Motion Detection that offer accurate analytics. The camera is ideal for a host of diverse applications — Enhanced Starlight Technology, True Wide Dynamic Range, and Smart Dual Illuminators allow the camera to operate in any lighting condition and the IP67 rating makes the camera suitable for the harshest environments.
Features:
- 1/2.8-in. 8MP Progressive-scan CMOS Sensor
- Triple-stream Encoding
- AI Coding, Smart H.265+, and Smart H.264+ Video Compression
- 8MP (3840 x 2160) at 30 fps, 2.7 mm to 13.5 mm Vari-focal Lens
- Analytics+ Functions — Perimeter Protection, Smart Motion Detection+
- Dual Built-in Microphones and a Built-in Speaker
- Voice Catcher Technology Captures Clear Audio at a Distance
- Smart Dual Illumination — IR and White Light
- Active Alarm with Red/Blue Lights and Siren or Voice Prompt
- Enhanced Starlight Technology for Low-light Applications
- IP67 Ingress Protection
- Five-year Warranty (when sold through an authorized Dahua dealer)
Camera
| Effective Pixels | 3840 (H) × 2160 (V) |
| RAM/ROM | 1 GB / 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto, Manual, 1/3 s to 1/100,000 s |
| Minimum Illumination | Color: 0.004 lux at F1.0 (30 IRE) B/W: 0.0004 lux at F1.0 (30 IRE) 0 lux at F1.0 (With Illuminators On) |
| S/N Ratio | > 56 dB |
| Illumination Distance | IR: 50.0 m (164.04 ft) White Light: 40.0 m (131.23 ft) |
| IR On/Off Control | Auto, Manual |
| Illuminators | IR: Two (2) LEDs White Light: Two (2) LEDs |
Lens
| Lens Type | Motorized Vari-focal | ||||
| Mount Type | φ16 | ||||
| Focal Length | 2.7 mm to 13.5 mm | ||||
| Max. Aperture | F1.0 | ||||
| Angle of View | Horizontal: 108° to 34° Vertical: 56° to 19° Diagonal: 130° to 39° | ||||
| Iris Type | Fixed | ||||
| Close Focus Distance | 1.50 m (4.92 ft) | ||||
DORI Distance¹ | Lens | Detect | Observe | Recognize | Identify |
| W | 89.9 m (294.95 ft) | 36.0 m (118.11 ft) | 18.0 m (59.06 ft) | 19.0 m (62.34 ft) | |
| T | 257.4 m (844.49 ft) | 103.0 m (337.93 ft) | 51.5 m (168.96 ft) | 25.7 m ( 84.32 ft) | |
| Range | Pan: 0° to 360° Tilt: 0° to 90° Rotation: 0° to 360° |
Network
| Ethernet | RJ-45 (10/100 Base-T) |
| Protocol | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP |
| Interoperability | SDK; API; ONVIF Profile S, G, T; CGI, Milestone; P2P |
| Streaming Method | Unicast / Multicast |
| Maximum User Access | 20 Users (Total Bandwidth: 72 Mbps) |
| Edge Storage | Network Attached Storage (NAS) Micro SD Slot (Maximum 256 GB) |
| Web Viewer | IE (Versions 8, 9, and 11) Chrome, Firefox |
| Management Software | DSS, DMSS |
| Mobile Operating System | iOS, Android |
| Cybersecurity | Video Encryption, Firmware Encryption, Configuration Encryption, Digest, WSSE, Account Lockout, Security Logs, IP/MAC Filtering, Generating and Importing X.509 Certification, Syslog, HTTPS, 802.1x, Trusted Boot, Trusted Execution, Trusted Upgrade |
