Hard Disk Drive-2TB, For Use with Dahua NVRs and HDCVI DVRs
Features :
Model |
ST1000VX005 |
ST2000VX015 |
ST3000VX009 |
ST4000VX013 |
ST6000VX001 |
ST8000VX0022 |
ST10000VE0008 |
|
Capacity |
1 TB |
2 TB |
3 TB |
4 TB |
6 TB |
8 TB |
10 TB |
|
Interface |
SATA 6 GB/s |
SATA 6 GB/s |
SATA 6 GB/s |
SATA 6 GB/s |
SATA 6 GB/s |
SATA 6 GB/s |
SATA 6 GB/s |
|
Cameras Supported |
up to 64 |
up to 64 |
up to 64 |
up to 64 |
up to 64 |
up to 64 |
up to 64 |
|
Cache |
64 MB |
256 MB |
256 MB |
256 MB |
256 MB |
256 MB |
256 MB |
|
Maximum Sustained Transfer Rate |
180 MB/s |
180 MB/s |
180 MB/s |
180 MB/s |
180 MB/s |
210 MB/s |
250 MB/s |
|
Startup Current,(typical at 12 V) |
1.8 A |
1.8 A |
1.8 A |
1.8 A |
1.8 A |
2.0 A |
1.8 A |
|
Average Operating Power |
5.6 W |
3.7 W |
5.6 W |
3.7 W |
5.0 W |
9.0 W |
6.9 W |
|
Average Idle Power |
4.0 W |
2.5 W |
4.0 W |
2.5 W |
3.4 W |
7.6 W |
4.9 W |
|
Operating Temperature |
0° C to 70° C (32° F to 158° F) |
0° C to 70° C (32° F to 158° F) |
0° C to 70° C (32° F to 158° F) |
0° C to 70° C (32° F to 158° F) |
0° C to 70° C (32° F to 158° F) |
5° C to 70° C (41° F to 158° F) |
5° C to 70° C (41° F to 158° F) |
|
Non-operating Temperature |
–40° C to 70° C (–40° F to 158° F) |
–40° C to 70° C (–40° F to 158° F) |
–40° C to 70° C (–40° F to 158° F) |
–40° C to 70° C (–40° F to 158° F) |
–40° C to 70° C (–40° F to 158° F) |
–40° C to 70° C (–40° F to 158° F) |
–40° C to 70° C (–40° F to 158° F) |
|
Weight |
415.0 g (0.915 lb) |
415.0 g (0.915 lb) |
490.0 g (1.08 lb) |
490.0 g (1.08 lb) |
610.0 g (1.345 lb) |
780.0 g (1.72 lb) |
650.0 g (1.43 lb) |
|
Dimensions,mm (in.)(H x W x D) |
20.20 x 101.85 x 146.99 (0.80 x 4.0 x 5.79) |
20.20 x 101.85 x 146.99 (0.80 x 4.0 x 5.79) |
20.20 x 101.85 x 146.99 (0.80 x 4.0 x 5.79) |
20.20 x 101.85 x 146.99 (0.80 x 4.0 x 5.79) |
26.11 x 101.85 x 146.99 (1.03 x 4.0 x 5.79) |
26.11 x 101.85 x 146.99 (1.03 x 4.0 x 5.79) |
26.11 x 101.85 x 146.99 (1.03 x 4.0 x 5.79) |
|
