ST4000VX013 - EOL
This product has been discontinued.
Part number:
ST4000VX013
Price:

Hard Disk Drive-4TB, For Use with Dahua NVRs and HDCVI DVRs



Features :

  • Designed for 24/7 Surveillance-optimized Hard Drive Applications
  • Engineered for Workloads up to 180 TB/year
  • Capacity Up to 10 TB, Supports 64 Cameras per Drive
  • Low Power Consumption and Startup Current
  • Tarnish-resistant Components to Minimize Environmental Effects

Model

ST1000VX005

ST2000VX015

ST3000VX009

ST4000VX013

ST6000VX001

ST8000VX0022

ST10000VE0008

Capacity

1 TB

2 TB

3 TB

4 TB

6 TB

8 TB

10 TB

Interface

SATA 6 GB/s

SATA 6 GB/s

SATA 6 GB/s

SATA 6 GB/s

SATA 6 GB/s

SATA 6 GB/s

SATA 6 GB/s

Cameras Supported

up to 64

up to 64

up to 64

up to 64

up to 64

up to 64

up to 64

Cache

64 MB

256 MB

256 MB

256 MB

256 MB

256 MB

256 MB

Maximum Sustained Transfer Rate

180 MB/s

180 MB/s

180 MB/s

180 MB/s

180 MB/s

210 MB/s

250 MB/s

Startup Current,(typical at 12 V)

1.8 A

1.8 A

1.8 A

1.8 A

1.8 A

2.0 A

1.8 A

Average Operating Power

5.6 W

3.7 W

5.6 W

3.7 W

5.0 W

9.0 W

6.9 W

Average Idle Power

4.0 W

2.5 W

4.0 W

2.5 W

3.4 W

7.6 W

4.9 W

Operating Temperature

0° C to 70° C

(32° F to 158° F)

0° C to 70° C

(32° F to 158° F)

0° C to 70° C

(32° F to 158° F)

0° C to 70° C

(32° F to 158° F)

0° C to 70° C

(32° F to 158° F)

5° C to 70° C

(41° F to 158° F)

5° C to 70° C

(41° F to 158° F)

Non-operating Temperature

–40° C to 70° C

(–40° F to 158° F)

–40° C to 70° C

(–40° F to 158° F)

–40° C to 70° C

(–40° F to 158° F)

–40° C to 70° C

(–40° F to 158° F)

–40° C to 70° C

(–40° F to 158° F)

–40° C to 70° C

(–40° F to 158° F)

–40° C to 70° C

(–40° F to 158° F)

Weight

415.0 g (0.915 lb)

415.0 g (0.915 lb)

490.0 g (1.08 lb)

490.0 g (1.08 lb)

610.0 g (1.345 lb)

780.0 g (1.72 lb)

650.0 g (1.43 lb)

Dimensions,mm (in.)(H x W x D)

20.20 x 101.85 x 146.99

(0.80 x 4.0 x 5.79)

20.20 x 101.85 x 146.99

(0.80 x 4.0 x 5.79)

20.20 x 101.85 x 146.99

(0.80 x 4.0 x 5.79)

20.20 x 101.85 x 146.99

(0.80 x 4.0 x 5.79)

26.11 x 101.85 x 146.99

(1.03 x 4.0 x 5.79)

26.11 x 101.85 x 146.99

(1.03 x 4.0 x 5.79)

26.11 x 101.85 x 146.99

(1.03 x 4.0 x 5.79)



Name
Description
Size
Downloads
File
Data Sheet
0.4mb
