The X88A Series HDCVI DVR offers 4K recording on each HDCVI channel and a host of advanced features and functions. The X88A takes advantage of HDCVI technology for easy integration into existing video surveillance systems while leveraging existing networks, cabling, and cameras. Penta-brid access technology seamlessly records video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously, plus the DVR delivers 4K resolution on each HDCVI or IP channel.
The Dahua Analytics+ algorithms significantly improve accuracy and reliability, as compared to standard intelligent features. The recorder offers advanced perimeter protection that distinguishes between human and vehicular violations, and real-time Facial Recognition with metadata that captures a person’s gender, age, and if the person is wearing glasses or a mask. This recorder is the ideal solution for actively monitoring public venues, retail stores, transportation hubs and access ways, personal property and homes, and educational institutions.
Features:
- 4K at 7 fps Recording Resolution on All HDCVI Channels
- Dual-stream Video Recording
- Smart H.265+ and Smart H.264+ Dual Codecs
- Auto-detection and Auto-configuration of Video Inputs
- 16+48 IP Camera Channels, each channel up to 12 MP
- Maximum 256 Mbps Incoming Bandwidth
- Supports RAID 0, 1, 5, 6, 10
- Analytics+ Functions: Face Recognition and Perimeter Protection
- Spot Output (HDMI2 Output)
- Five-year Warranty (for products sold through an authorized Dahua dealer)
| System | |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Analytics+ Perimeter Protection¹ |
| Performance | • Human and Vehicle object classification • Decreased false alarms from leaves, lights, animals • Configure function on 16 channels, • 10 Tripwire/Intrusion rules per channel |
| Object Classification | • Human or Vehicle • Secondary Recognition for Tripwire and Intrusion |
| Search | • Search by object classification (human or vehicle) |
| Analytics+ Face Recognition¹,² |
| Performance | • Process 24 facial images per second • Total of six (6) channels: up to four (4) analog channels and up to two (2) IP channels |
| Stranger Mode | • Detects a face not stored in the database. • Similarity Threshold set manually |
| Search by Image | • Up to eight (8) target face image searches simultaneously • Supports Similarity Threshold for each target face image |
| Database Management | • 20 Face Databases • 100,000 total face images • Stores name, gender, birthday, nationality, address, ID information for each face picture |
| Database Application | Each database can be applied to video channels independently. |
| Trigger Events | Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation |
