Digital Watchdog - DWC-B6263WTIRW - Star-Light 2.1MP/1080p UHDoC Bullet Camera with a Vari-focal Lens and IR
STAR-LIGHT 2.1MP, 1080p Universal HD over Coax cameras deliver crystal-clear images and support real-time 30fps HD-Analog, HD-TVI, HD-CVI and all analog signals to 960H. STAR-LIGHT Universal HD over COAX cameras are engineered to work with our VMAX A1 Universal HD over COAX DVRs using your existing coax infrastructure for a cost-effective, high resolution surveillance solution.
Star-Light Super Low-Light Technology
Star-Light Technology provides crisp clear images in both color and B/W video in extremely low light conditions. It is an ideal solution for cameras that are installed in a low-light environment, and cannot rely on external lighting for image clarity. Coupled with a powerful IR built-in, Star-Light cameras can provide unparalleled details in total darkness.
True Wide Dynamic Range (WDR)
Cameras with True Wide Dynamic Range (WDR) technology have advanced sensors that can process a wider range of lighting, dark and bright in the same image.
Features:
- Universal HD over Coax Technology with HD-Analog, HD-TVI, HD-CVI and all Analog to 960H Signal Support
- STAR-LIGHT Super Low Light Technology
- 2.1MP 1/3" Image Sensor at Real-time 30fps
- 2.8~12mm Varifocal P-Iris Lens
- True Wide Dynamic Range (WDR)
- OSD Control Via Coaxial (UTC)
- 100' Smart IR with Intelligent Camera Sync.
- Smart DNR 3D Digital Noise Reduction
- True Day/Night Mechanical IR Cut Filter
- De-Fog Extreme Weather Image Compensation
- Highlight Masking Exposure (HME)
- Auto-Sensing 24VAC/12VDC with Line Lock
- Easy Icon Driven OSD Menu with Built-in Joystick
- Programmable Privacy Zones
- Auto Gain Control (AGC)
- Backlight Compensation (BLC)
- Dynamic Range Compressor (DRC) Reveals Low Light Detail
- Auto White Balance (AWB)
- RS-485 Built-in
- UL listed
- NDAA compliant
- IP66 Certified Weather and Tamper Resistant
- 5 Year Warranty
| IMAGE | |
| Active Pixels | 1944 (H) x 1092 (V) |
| Frequency | 50Hz, 60Hz |
| Image sensor | 2.1MP/1080p 1/3" CMOS sensor |
| Maximum resolution | 2.1MP/1080p |
| Minimum Scene Illumination in color | 0.0 lux (B/W), 0.03 lux (color) |
| Scanning System | Progressive scan |
| Signal technology | CVBS up to 960H, HD-Analog, HD-CVI, HD-TVI, Universal HD over Coax® technology |
| LENS | |
| Advanced Lens Features | P-iris |
| Focal Length | 2.8mm ~ 12mm |
| Horizontal Field of View (HFOV) | 91° ~ 28° |
| IR Distance | 100' range Smart IR™ |
| Lens Type | Vari-focal Lens |
| Vertical Field of View (VFOV) | 47.8° ~ 18.7° |
| I/O | |
| I/O Alarm in/out | 1 output |
| OPERATIONAL | |
| 3D digital noise reduction | Smart DNR™ 3D Digital Noise Reduction |
| Auto gain control | Auto |
| Backlight compensation (BLC) | Yes |
| Camera Control | Pelco C, Pelco D, UTP built-in |
| Day and night | Auto day/night, Day (color), Night (B/W) |
| De-fog | Yes |
| DRC | Yes |
| Gamma | 0.45 ~ 0.75 |
| Mirror/flip | Yes |
| Motion Detection | Yes |
| Privacy Zones | 16 programmable privacy masks |
| Sharpness | Yes |
| Shutter Mode | Anti-Flicker, Auto, Manual |
| Shutter Speed | 1/30 ~ 1/30000 |
| Star-Light (sense up) | Off, x2-x32 |
| White Balance | Yes |
| Wide Dynamic Range (WDR) | True WDR 100dB |
| Environmental Operating Humidity | 10-90% (non-condensing) |
| Environmental Operating Temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Mounting Accessories (Required/Optional) | Optional. Sold separately |
| MECHANICAL | |
| Camera Dimensions (H X W X D) | *Dimensions based on the position of the sun shield cover, 8.83" x 3.8" (224.5 x 96.7 mm) |
| Camera Weight | 1.65 lbs (0.75kg) |
| Housing | Bullet |
| Housing Color | White |
| IP rating | Weather Resistant (IP66) |
| Materials | Aluminum die-casting |
| ELECTRICAL | |
| American wire gauge (AWG) | Cable type #18 |
| Power Consumption | AC24V (LED on): 4.3W, 179.1mA, AC24V (no LED): 2.7W, 112.5mA, DC12V (LED on): 4.44W, 370mA, DC12V (no LED): 3.0W, 250mA |
| Power Requirements | 12V DC, 24 V AC |
| GENERAL | |
| Warranty | 5 Year Warranty |
