Digital Watchdog - DWC-MPB48WiAT - MEGApix IVA+ 4K bullet IP camera with a vari-focal lens, IR and IVA+
Part number:
DWC-MPB48WiAT
Price:
MEGApix IVA+ Weather Resistant Bullet, Star-Light Plus, 4K , Star-Light Plus, 2952x2320 @ 30fps, 2.7-13.5mm Autofocus Varifocal P-Iris Lens, 140ft Smart IR, T-WDR, 3D-DNR, True D&N, Alarm In/RelayOut,Triple Codecs (H.265, H.264, MJPEG) with Simultaneous Streaming, Two Way Audio, PoE Class 3 and DC12V, OnVIF Compliant, Micro SD/SDHC/SDXC class 10 card slot (card not included) IP66, IK10, NDAA, 5 Year Warranty. NOTE: Intelligent Video Analytics Basic inside.
Features:
- 4K 1/2.8” image sensor at real-time 30fps
- Star-Light Plus™ color in near-total darkness technology
- Intelligent Video Analytics (IVA pre-loaded models)
- Extended Intelligent Video Analytics (IVA+ pre-loaded models)
- Seamless integration and control of IVA rules with DW Spectrum® IPVMS
- Reduce false alarms
- Increase your recording storage with logic rules and smart recording
- 2.7~13.5mm vari-focal p-iris lens with motorized zoom and auto-focus
- True Wide Dynamic Range (WDR)
- Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
- Cold Start -40°F (-40°C)
- 140’ Smart IR™ with intelligent camera sync
- Smart DNR™ 3D digital noise reduction
- True day/night with mechanical IR cut filter
- Programmable privacy zones
- Auto gain control (AGC)
- Backlight compensation (BLC)
| ENVIRONMENTAL | |
|---|---|
| Compliance | NDAA Compliance CF FCC RoHS ONVIF |
| Operating Humidity | 10-90% (non-condensing) |
| Operating Temperature | -40°F ~ 122°F (-40°C ~ 50°C) |
| I/O | |
| Audio compression | G.711 |
| I/O Alarm in/out | 1 input 1 output |
| I/O Audio in/out | 1 input 1 output *Cameras provide a line level audio. The use of amplified microphones and speakers is recommended. |
| IMAGE | |
| Active Pixels | 3840 (H) x 2160 (V) |
| Image Resolution | 4K |
| Signal technology | HD-TVI |
| Test Video Output | Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio |
| Total Pixels | 3952 (H) x 2320 (V) |
| LENS | |
| Advanced Lens Features | Motorized zoom Auto focus P-iris |
| Focal Length | 2.7mm ~ 13.5mm |
| Horizontal Field of View (HFOV) | 90.3° ~ 33.1° |
| Image sensor | 4K 1/2.8" CMOS sensor |
| IR Distance | 140" range Smart IR™ |
| Lens Type | Vari-focal Lens |
| Minimum Scene Illumination in color | 0.09 lux (color) 0.0 lux (B/W) |
| Veritcal Field of View (VFOV) | 18.9°~49 |
| MECHANICAL | |
| Housing | Bullet |
| IK rating | IK10 Rated |
| IP rating | Weather Resistant (IP67) |
| Materials | Aluminum die-casting |
| Mechanical Dimensions | 4.66" x 3.58" (118.6 x 91 mm) *Dimensions based on the position of the sun shield cover |
| Weight | 2.64 lbs (1.2 kg) |
| OPERATIONAL | |
| 3D digital noise reduction | 3D DNR |
| Auto gain control | Auto |
| Backlight compensation (BLC) | Yes |
| Day and night | Auto day/nighy Day (color) Night (B/W) |
| De-fog | Yes |
| Intelligent Video Analytics | IVA license: intrusion, line crossing, counting line, loitering, enter, exit, tamper |
| Memory slot | Micro SD/SDHC/SDXC class 10 card (card not included) |
| Mirror/flip | Yes |
| Motion Detection | Yes |
| Notifications | Email FTP server Alarm output activation SD card recording |
| Operational features | Star-Light Plus True D/N |
| Privacy Zones | 16 programmable privacy masks |
| Sharpness | Yes |
| Shutter Mode | Auto Manual Slow Shutter Anti-Flicker |
| Shutter Speed | 1/15 ~ 1/32000 |
| Slow Shutter Speed | Off x2 x3 x5 x6 x7.5 x10 |
| White Balance | Yes |
| Wide Dynamic Range (WDR) | True WDR 120dB |
| GENERAL | |
| General Warranty | 5 Year Warranty |
| Power Consumption | DC12V: 10.2W, 850mA PoE: 16W |
| Power Requirements | 12 V DC PoE IEEE 802.3at PoE+ class 4 (Adapter not included) |
| NETWORK | |
| Bitrate Control | Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth) |
| IP | IPv4 |
| LAN | 1000Base-T (1Gbps) |
| Network resolution | H.265: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF H.264: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF MJPEG: 2.1MP/1080p, 720p, 800x600, VGA, 768x432, D1, CIF |
| Protocol | DDNS DHCP DNS FTP HTTP HTTPs ICMP NTP ONVIF RTP (UDP/TCP) RTSP SMTP SNMPv1/v2/v3 (MIB-2) SSL TCP/IP UDP Zeroconf (AutoIP) |
| Security | HTTPS (TLS) IP filtering 802.1x Digest authemtication (ID/PW) |
| Stream Speed | Up to 30fps at all resolutions |
| Streaming Capability | Dual-stream at different rates and resolutions |
| Video Bitrate | 100Kbps~10Mbps, multi-rate for preview and recording |
| Video Compression Type | H.264 H.265 MJPEG |
| Video Management Software | DW Spectrum® IPVMS Any ONVIF conformant CMS |
| Web Viewer | Windows® OS Mac® OS Linux® OS Internet Explorer® browser Google Chrome® browser Mozilla Firefox® browser Safari® browser |
Name
Description
Size
Downloads
File
Datasheet
0.7mb
