Digital Watchdog - DWC-XSTD05MF - MEGApix Ai Indoor/Outdoor Vandal Turret Camera, Ai Deep Learning, Star-Light Plus, 5 Megapixel 1/2.8” Image Sensor (2592x1944 @ 30fps), 2.7-12mm autofocus varifocal Lens,90ft White Light IR, Red and Blue Flashing LED
Part number:
DWC-XSTD05MF
Price:
This NDAA/TAA-compliant MEGApix Ai turret IP camera provides 5MP resolution at real-time 30fps with 90ft range white light, with red/blue flash LEDs built-in and an edge Ai engine onboard. MEGApix Ai cameras place the power of Ai deep learning at your fingertips, with object detection and people tracking. This camera features Star-Light Plus color in near-total darkness technology and a built-in microphone and speaker in an IP67-rated, IK10- rated housing.
Features:
- 5MP sensor at real-time 30fps
- Star-Light Plus color in near-total darkness technology
- AI Deep Learning object detection
- Create up to 40 separate detection zones.
- Easy setup with no analytics calibration
- Seamless integration and control with DW Spectrum IPVMS
- Reduce false alarms with multiple detection zones and logical rules.
- Increase your recording storage with smart recording and no false alarms.
- 90' white light illumination and red/blue flash LEDs for video, illumination and deterrence in a single camera installation
- Vari-focal p-iris lens with motorized zoom and autofocus for complete remote lens control and focused image any time
- True Wide Dynamic Range (WDR) for clear images in challenging light
- Simultaneous streaming and multiple codec options for smart bandwidth management
- Smart DNR 3D digital noise reduction reduces noise and ghosting for motion in low-light environments.
- Privacy zones cover sensitive areas in the camera's field of view.
- Two-way audio with built-in microphone and speaker for direct communication between the monitoring station and the camera's location
- Local SD card slot for local recording in case of network loss
- Alarm sensor input and relay output for access control integration
- Web server built-in for easy camera management from any browser
- High-power PoE and DC12V for single cable simplified installation
- NDAA/TAA compliant for federal and government projects
- IP67- and IK10-rated camera housing built to last
- 5 year warranty
| Specifications | |
| IMAGE | |
| Color temperature | 3000K, Warm light |
| WL wavelength (lumen) | 200lm |
| Active Pixels | 2592 (H) x 1944 (V) |
| Frequency | 50Hz |
| Image sensor | 5MP 1/2.8" CMOS sensor, Star-Light Plus™ sensor |
| Maximum resolution | 5MP |
| Minimum Scene Illumination in color | 0 lux (white light), 0.03 lux (color) |
| Total Pixels | 2608(H) X 1984(V), 2704(H) X 2104(V) |
| LENS | |
| Advanced Lens Features | Auto focus, Motorized zoom, P-iris |
| Focal Length | 2.7 - 12mm |
| Horizontal Field of View (HFOV) | 89.9° - 31.5° |
| Lens Type | Vari-focal Lens |
| Vertical Field of View (VFOV) | 64.5° - 23.6° |
| White Light Distance | 90' range white light |
| I/O | |
| Audio compression | G.711 ulaw |
| Event triggers | Illegal login, Motion Alarm, Network disconnection, Schedule, Sensor detection, Temperature anomaly |
| I/O Alarm in/out | 1 input, 1 output |
| I/O Audio in/out | 1.5 Watts, 1 microphone built-in, 1 speaker built-in |
| INTELLIGENT VIDEO ANALYTICS | |
| Deep learning analytics | Deep Learning object tracking |
| Analytics filters | Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear, stopped, enter, exit, direction, tailgating, dwell, logical rules |
| OPERATIONAL | |
| 3D digital noise reduction | Smart DNR™ 3D Digital Noise Reduction |
| Auto gain control | Auto |
| Day and night | Day (color) |
| De-fog | Yes |
| Memory slot | Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32 |
| Mirror/flip | Yes |
| Motion Detection | Yes |
| Operational Notifications | Flashlight, Alarm output activation, Email, FTP server, SD card recording |
| Privacy Zones | 16 programmable privacy masks |
| Sharpness | Yes |
| Shutter Mode | Anti-Flicker, Auto, Manual, Slow Shutter |
| Shutter Speed | 1/15 ~ 1/32000 |
| Slow Shutter Speed | Off, x10, x2, x3, x5, x6, x7.5 |
| White Balance | Yes |
| Wide Dynamic Range (WDR) | True WDR 120dB |
| NETWORK | |
| Bitrate Control | Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth) |
| IP | IPv4 |
| LAN | RJ45 (10/100Base-T) |
| Network resolution | H.264: 2592x1944, 2560x1440, 1920x1080, 1280x720, 800x600, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240, H.265: 2592x1944, 2560x1440, 1920x1080, 1280x720, 800x600, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240, MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240 |
| Network Web Viewer | Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS |
| Protocol | DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP) |
| Security | 802.1x, Digest authemtication (ID/PW), HTTPS (TLS), IP filtering |
| Stream Speed | Up to 30fps at all resolutions |
| Streaming Capability | Triple Streaming (3rd stream supports MJPEG only), Triple Streaming (3rd stream MJPEG only) |
| Video Bitrate | 100Kbps ~ 25Mbps, multi-rate for preview and recording |
| Video Compression Type | H.264, H.265, MJPEG |
| Video Management Software | Any ONVIF conformant CMS, DW Spectrum® IPVMS |
| ENVIRONMENTAL | |
| Environmental Operating Humidity | 10-90% (non-condensing) |
| Environmental Operating Temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Mounting Accessories (Required/Optional) | Optional. Sold separately |
| MECHANICAL | |
| Camera Dimensions (H X W X D) | 4.92" x 4.79" (125 x 121.7 mm) |
| Camera Weight | 1.94 lbs (0.88 kg) |
| Housing | Vandal ball turret, Turret |
| Housing Color | White |
| IK rating | IK10 Rated |
| IP rating | Weather Resistant (IP67) |
| Materials | Aluminum die-casting |
| ELECTRICAL | |
| American wire gauge (AWG) | 30M, Cable type #18 |
| Power Consumption | DC12V: max 12W, 1A, PoE: max 15.8W, 287mA |
| Power Requirements | Adapter not included, PoE |
| GENERAL | |
| Warranty | 5 Year Warranty |
