Engenius - ENH1350EXT - EnTurbo AC1300 Wave 2 Outdoor Access Point
Part number:
ENH1350EXT
Price:
Extend your high-speed wireless coverage to the outdoors with the ENH1350EXT, a Wave 2 Outdoor 11ac, 2x2, MU-MIMO, Dual-Band Wireless AC1300 Access Point. Reaching speeds to 867 Mbps on 5 GHz and to 400 Mbps on the 2.4 GHz frequency band, this feature-rich AP leverages advanced Wi-Fi and Beamforming antenna technology, maximizing performance and reliability while greatly increasing outdoor network user capacities. The AP is designed to operate in harsh environmental conditions and includes an IP67-rated waterproof and dustproof casing to protect it from the elements.
Features:
- 11ac Wave 2 Wireless Speeds to 867Mbps on 5GHz; to 400Mbps on 2.4GHz
- IP67-Rated Weatherproof & Dust-proof Housing Withstands Harsh Environments
- Dual-Radio MU-MIMO Improves Performance & Expands User Capacities
- Beamforming Optimizes Antenna Signal, Reception & Reliability for Clients
- 4 Detachable 5dBi High-Gain, 360° SMA-Type Antennas
- Proprietary 48V PoE
Technical Specifications |
Standards |
| IEEE 802.11b/g/n on 2.4GHz |
IEEE802.11a/n/ac on 5GHz
|
Antenna |
| Four (4) External 5 dBi Dual-Concurrent Omni-Directional Antenna |
SMA-Type
|
Physical Interface |
| 1 x 10/100/1000 Gigabit Ethernet Ports |
1 x Reset Button
|
LED Indicators |
| 1 x Power |
| 1 x LAN |
| 1 x 2.4 GHz |
1 x 5 GHz
|
Power Source |
| Power-over-Ethernet: Proprietary 48V PoE |
Active Ethernet (PoE)
|
Maximum Power Consumption |
| 12.6W |
Surge Protection |
| 1KV |
ESD Protection |
| Air: 8 KV |
Wireless & Radio Specifications |
Operating Frequency |
| Dual-Radio Concurrent 2.4GHz & 5 GHz |
Operation Modes |
| Access Point Mode (AP Mode) |
| Client Bridge Mode (CB Mode) |
| WDS: AP Mode and Bridge Mode (Mesh Mode Coming Soon) |
Frequency Radio |
| 2.4GHz: 2400 MHz ~ 2835 MHz |
| 5GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725MHz ~ 5850MHz |
Transmit Power |
| 2.4 GHz: 15 dBm |
| 5 GHz: 15 dBm |
| Tx Beamforming (TxBF) |
| Radio Chains/Spatial Stream |
| 2 x 2:2 |
SU-MIMO |
| Two (2) Spatial Stream SU-MIMO up to 1267 Mbps to a single client |
MU-MIMO |
| Two (2) Spatial Stream MU-MIMO up to 1267 Mbps to two (2) MU-MIMO capable wireless devices simultaneously |
Supported Data Rates (Mbps) |
| 2.4 GHz: Max 400 |
| 5 GHz: Max 867 |
| 802.11b: 1, 2, 5.5, 11 |
| 802.11a/g: 6, 9, 12, 18, 36, 48, 54 |
| 802.11n: 6.5 to 400 Mbps (MCS0 to MCS15) |
| 802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2) |
Supported Radio Technologies |
| 802.11b: Direct-Sequence Spread Spectrum (DSSS) |
| 802.11a/g/n/ac: Orthogonal Frequency-Division Multiplexing (OFDM) |
| 802.11n/ac: 2×2 MIMO with 2 Streams |
Channelization |
| 802.11ac supports very high throughput (VHT)—VHT 20/40/80 MHz |
| 802.11n supports high throughput (HT)—HT 20/40 MHz |
| 802.11n supports very high throughput (VHT) under the 2.4 GHz radio—VHT (256-QAM) |
| 802.11n/ac packet aggregation: AMPDU, ASPDU |
Supported Modulation |
| 802.11b: BPSK, QPSK, CCK |
| 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM |
| 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM |
Management Features |
Multiple BSSID |
| Supports 16 SSIDs (8 SSIDs per band) |
VLAN Tagging |
| Supports 802.1q SSID-to-VLAN Tagging |
| Cross-band VLAN Pass Through |
| Management VLAN |
QoS (Quality of Service) |
| Complaint with IEEE 802.11e Standard |
Band Steering |
| RSSI Threshold |
| Traffic Shaping |
| Save Configuration as Default |
| Auto Transmit Power |
| Auto Channel Selection |
| Site Survey |
| PMK Caching |
Control Features |
| Distance Control (ACK Timeout) |
| Multicast Supported |
| Fast Roaming |
| Email Alerts |
| Wi-Fi Scheduler |
| Client Traffic Status |
| Guest Network |
| RADIUS Accounting |
| Power Save Mode (U-APSD Support) |
| CLI Support |
Wireless Security |
| WEP Encryption 64/128/152 bit |
| WPA/WPA2 Enterprise (WPA-EAP using TKIP or AES) |
| Hide SSID in Beacons |
| MAC Address Filtering, Up to 64 MACs per SSID |
| Wireless STA (Client) Connected List |
| Https |
| SSH |
| Client Isolation |
Environmental & Physical |
| Temperature Range |
| Operating: -4º~140ºF/-20ºC~60ºC |
| Storage: -22Fº~176ºF/-40ºC~80ºC |
Humidity (non-condensing) |
| Operating: 90% or less |
| Storage: 90% or less |
Waterproof & Dustproof |
| IP67-Rated Enclosure |
Dimensions & Weight |
| ENH1350EXT Device |
| Width: 4.37” (111.2 mm) |
| Length: 6.83” (173.6 mm) |
| Height” 1.19” (30.29 mm) |
Package Contents |
| 1 – ENH1350EXT Dual-Band AC1300 Outdoor Access Point |
| 1 – Power Adapter (54V/0.6A) |
| 1 – PoE Adapter (EPA5006GR) |
| 2 – Pole-Mounting Brackets |
| 1 – Wall-Mount Screw Set |
| 2 – 2.4GHz 5dBi SMA Antennas |
| 2 – 5GHz 5dBi SMA Antennas |
| 1 – Quick Installation Guide |
Certifications |
| FCC |
| CE |
