Engenius - EPA2406GR - Gigabit Proprietary PoE Adapter with Reset Button
Part number:
EPA2406GR
Price:
- • Gigabit Ethernet in & out ports allow connection of high-speed devices
- • Delivers both data and power to EnGenius outdoor access point
- • PoE injector reset button positioned conveniently near ground level
- • Optimal port design for easy mounting/positioning
- • Compact design
- • Extends power to unwired areas up to 328-ft./100m
- • Disconnect, short-circuit & surge protection assures secure, reliable connections
- • Mounts to walls or ceilings with included hardware
| Proprietaries | |
|---|---|
| Ethernet Standards | • 802.3 10BaseT • 802.3u 100BaseT • 802.3ab 1000Base-T Ethernet |
| Power over Ethernet | Proprietary PoE |
| Compliance | |
| Safety & Emissions | • IEC 60950-1:2005+A1 • UL60950-1 • ENS55022:2010 • EN55024:2010 • FCC Part 15 Class B • FCC, CE |
| Physical Interface | |
| Ports | • (1) Gigabit Data Port • (1) Gigabit Data & Power Output Port |
| Power Input | • (1) IEC-320 C6 AC Connector |
| Reset | • (1) Reset Button |
| LED Indicator | |
| Indicator | • 1 x Power on Green |
| Mounting | |
| Type | Wall (anchors & screws included) |
| Power | |
| Input Voltage | 100 to 240VAC |
| Input Current | • 0.4A @ 120V AC • 0.24A @ 240V AC |
| AC Input Frequency | 50-60Hz |
| Maximum Output Power | 14.4 W |
| Power Lines | Pin4(Vdc+) & Pin5(Vdc+); Pin7(Vdc-) & Pin8(Vdc-) |
| Data Lines | Pin1(Rx+) & Pin2(Rx-); Pin3(Tx+) & Pin6(Tx-) |
| Surge Protection | L-L: 2KV; L-G: 2KV |
| ESD Protection | Contact: 4KV; Air: 8KV |
| Environmental & Physical | |
| Temperature Range (Operating) | 32°F to 104°F (0°C to 40°C) |
| Temperature Range (Storage) | -4°F to 158°F (-20°C to 70°C) |
| Humidity (Operating, non-condensing) | 5 to 90% or less |
| Humidity (Storage, non-condensing) | 5 to 90% or less |
| Device Dimensions & Weights | |
| EEPA2406GR Device (Without Mounting Kit) | • Weight: .33 lbs. (154 g) • Length: 3.9” (99 mm) • Width: 2.27” (68.5 mm) • Height: 1.3” (33 mm) |
| Packaging | • Weight: .57 lbs. (262 g) • Length: 5.4” (139 mm) • Width: 4.8” (122.5 mm) • Height: 2” (52 mm) |
| Package Contents | |
| Included Items | • EPA2406GR • Power cord |
| Warranty | |
| Duration | 1 Year |
The EnGenius EPA2406GR Gigabit Proprietary Power-over-Ethernet adapter supports high-speed data and up to 14.4 watts of power. Compact port design provides easy installation, and built-in power surge protection preserves valuable equipment. A PoE injector, placed closer to ground level, has a reset button that allows administrators to reset devices conveniently without having to take them down.
