GeoVision - GV-BX2700-FD - Starlight 2MP H.265 Super Low Lux WDR Pro Face Detection Box IP Camera
Part number:
GV-BX2700-FD
Price:

GV-BX2700-FD is specifically designed for face detection. The camera can support H.265 video codec to achieve better compression ratio while maintaining high picture quality at reduced network bandwidths. It is equipped with a super low lux CMOS image sensor which allows the camera to provide a color live view in near darkness. It features a mini USB port which supports wireless connection through a GV-WiFi Adapter (optional) or external storage using a USB hard drive.


Features:

  • 1/2.8" progressive scan super low lux CMOS
  • Min. illumination at 0.004 lux
  • Triple streams from H.265, H.264 and MJPEG
  • Up to 30 fps at 1920 × 1080
  • P-Iris for auto iris adjustment
  • Built-in / external microphone
  • Two-way audio
  • One sensor input and one alarm output
  • TV-out support
  • Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I) for local storage
  • Recording assigned by GV-Edge Recording Manager (Windows & Mac version)
  • Mini USB slot for WiFi Adapter or USB hard drive
  • Wide Dynamic Range Pro (WDR Pro)
  • Face Detection
  • 3D noise reduction
  • Smart streaming
  • Defog
  • Privacy mask
  • IP address filtering
  • DC 12V / PoE (IEEE 802.3af)
  • Day and Night function (with removable IR-cut filter)
  • Megapixel varifocal lens
  • Support for iPhone, iPad, Android & 3GPP
  • 31 languages on Web interface
  • ONVIF (Profile S, T) conformant



Note:

  • Face detection requires GV-VMS 18.1 or later.
  • Specifications are subject to change without notice.
Camera
Image Sensor1/2.8" progressive scan super low lux CMOS
Picture Elements1920 (H) x 1080 (V)
Minimum IlluminationColor 0.005 Lux
B/W0.004 Lux
IR ON0 Lux
Shutter SpeedAutomatic, Manual (1/30 ~ 1/16,000 sec)
White BalanceAutomatic, Manual (2800 ~ 8500K)
Gain ControlAutomatic
S/N Ratio56 dB
WDR ProYes
Dynamic Range130 dB
Lens
MegapixelYes
Day/NightYes (with removable IR‐cut filter)
Lens TypeVarifocal
Focal Length3 ~ 10.5 mm
Maximum ApertureF/1.4
MountCS Mount
Image Format1/2.7"
Horizontal FOV100° ~ 35°
OperationFocusManual (w/lock)
ZoomManual (w/lock)
IrisP‐Iris
